Trane A4AH6E19A1B30B User Manual

18-GF14D1-1C-EN
15
Performance and Electrical Data
Table 4. Air Flow Performance
A4AH6E19A1B30B
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps — 208 – 230 VOLTS
High Med-High
Med † Low
0.1 860 773 652 589
0.2 817 732 589 528
0.3 767 679 515 445
0.4 709 612 431 339
0.5 644 533 336 210
0.6 571 441 232
0.7 491 336 116
1. Values are with wet coil, no filter, and no heaters
2. CFM Correction for dry coil = Add 3%
3. † = Factory Setting
4. Low = Taps 1–2, Med = Tap 3, Med-High= Tap 4, High = Tap 5
Table 5. Electrical Data
A4AH6E19A1B30B
Heater Model No.
No. of
Circuits/
Phases
240 Volt 208 Volt
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
ProtectionkW BTUH kW BTUH
No Heater 4.1 * 8 15 4.1 * 8 15
BAYHTR1504BRK
BAYHTR1504LUG
1/1
3.8 13100 16.0 28 30 2.9 9800 13.8 25 25
BAYHTR1505BRK
BAYHTR1505LUG
1/1
4.8 16400 20.0 33 35 3.6 12300 17.3 29 30
BAYHTR1508BRK
BAYHTR1508LUG
1/1
7.7 26200 32.0 48 50 5.8 19700 27.7 42 45
BAYHTR1510BRK
BAYHTR1510LUG
1/1
9.6 32800 40.0 58 60 7.2 24600 34.6 51 60
BAYHTR3510LUG
1/3
9.6 32800 23.1 36 40 7.2 24600 20.0 32 35
* = Motor Amps
