Table 23. Electrical Data
A4AH6V48A1C30B, A4AH6V60B1C30A HEATER DATA
Heater Model No.
No. of
Circuits/
Phases
240 Volt 208 Volt
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater 6.8 * 9 15 6.8 * 9 15
BAYHTR1504BRK
BAYHTR1504LUG
1/1
3.84 13100 16.0 29 30 2.88 9800 13.8 26 30
BAYHTR1505BRK
BAYHTR1505LUG
1/1
4.80 16400 20.0 34 35 3.60 12300 17.3 30 30
BAYHTR1508BRK
BAYHTR1508LUG
1/1
7.68 26200 32.0 49 50 5.76 19700 27.7 43 45
BAYHTR1510BRK
BAYHTR1510LUG
1/1
9.60 32800 40.0 59 60 7.20 24600 34.6 52 60
BAYHTR1517BRK
Circuit 1
(a)
2/1
9.60 32800 40.0 59 60 7.20 24600 34.6 52 60
BAYHTR1517BRK
Circuit 2
4.80 16400 20.0 25 25 3.60 12300 17.3 22 25
BAYHTR1523BRK
Circuit 1
2/1
9.60 32800 40.0 59 60 7.20 24600 34.6 52 60
BAYHTR1523BRK
Circuit 2
9.60 32800 40.0 50 50 7.20 24600 34.6 43 45
BAYHTR1525BRK
Circuit 1
4/1
6.00 20500 25.0 40 40 4.50 15400 21.6 36 40
BAYHTR1525BRK
Circuit 2
6.00 20500 25.0 31 35 4.50 15400 21.6 27 30
BAYHTR1525BRK
Circuit 3
6.00 20500 25.0 31 35 4.50 15400 21.6 27 30
BAYHTR1525BRK
Circuit 4
6.00 20500 25.0 31 35 4.50 15400 21.6 27 30
BAYHTR3510LUG
1/3
9.60 32800 23.1 36 40 7.20 24600 20.0 33 35
BAYHTR3517LUG
1/3
14.40 49100 34.6 51 60 10.80 36900 30.0 45 45
* = Motor Amps
(a)
MCA and MOP for circuit 1 contains the motor amps
