Trane ACYSTAT220AA User Manual

6
ACYSTAT-IOM-EN
Wireless Remote Control
There are four major components of the Wireless Remote
Control system as follows:
(1) Control Box Assembly
(2) Display Unit and Receiver Board
(LCD or Touch wired control)
(3) Hand Held Remote Controller
(4) Cable (standard assembly length
4 meters)
Components (1) and (4), along with the system fan coil
or air handler are concealed in the building structure and
do not require access by the system operator. The visible
and accessible components are components (2) and (3)
as shown below.
Display Unit and Receiver Board
Figure 2 - LCD Wired Conrol
Handheld Remote Controller
Figure 4
Display Unit and Receiver Board
Figure 3 - Touch Wired Control

Trane ACYSTAT220AA Specifications

General

Brand	Trane
Model	ACYSTAT220AA
Category	Control Systems
Language	English
