4A6H5060H-SUB-1A-EN
3
Product Specifications
OUTDOOR UNIT
(a) (b)
4A6H5060H1000A
POWER CONNS. — V/PH/HZ
(c)
208/230/1/60
MIN. BRCH. CIR. AMPACITY 31
BR. CIR. PROT. RTG. — MAX. (AMPS)
50
COMPRESSOR DURATION™- SCROLL
NO. USED — NO. STAGES 1 — 1
VOLTS/PH/HZ 208/230/1/60
R.L. AMPS
(d)
— L.R. AMPS
23.7 — 152.5
FACTORY INSTALLED
START COMPONENTS
(e)
NO (Uses BAYKSKT263)
INSULATION/SOUND BLANKET
NO
COMPRESSOR HEAT NO
OUTDOOR FAN PROPELLER
DIA. (IN.) — NO. USED
27.6 — 1
TYPE DRIVE — NO. SPEEDS DIRECT — 1
CFM @ 0.0 IN. W.G.
(f)
4992
NO. MOTORS — HP
1 — 1/3
MOTOR SPEED R.P.M. 850
VOLTS/PH/HZ 200/230/1/60
F.L. AMPS 2.80
OUTDOOR COIL — TYPE SPINE FIN™
ROWS — F.P.I. 2 — 24
FACE AREA (SQ. FT.)
29.15
TUBE SIZE (IN.)
3/8
REFRIGERANT CONTROL EXPANSION VALVE
REFRIGERANT
LBS. — R-410A (O.D. UNIT)
(g)
10 LBS., 9 OZ
FACTORY SUPPLIED YES
LINE SIZE — IN. O.D. GAS
(h) (i)
1–1/8
LINE SIZE — IN. O.D. LIQ.
3/8
CHARGING SPECIFICATIONS
SUBCOOLING 8°F
DIMENSIONS H X W X D
CRATED (IN.)
51 x 38.7 x 35.1
WEIGHT
SHIPPING (LBS.)
301
NET (LBS.)
251
(a)
Certified in accordance with the Air-Source Unitary Air-conditioner
Equipment certification program, which is based on AHRI standard
210/240.
(b)
Rated in accordance with AHRI standard 270.
(c)
Calculated in accordance with Natl. Elec. Codes. Use only HACR
circuit breakers or fuses.
(d)
This value shown for compressor RLA on the unit nameplate and on
this specification sheet is used to compute minimum branch circuit
ampacity and max. fuse size. The value shown is the branch circuit
selection current.
(e)
No means no start components. Yes means quick start kit
components. PTC means positive temperature coefficient starter.
Optional kit shown.
(f)
Standard Air — Dry Coil — Outdoor
(g)
This value approximate. For more precise value see unit nameplate.
(h)
Reference the outdoor unit ship-with literature for refrigerant piping
length and lift guidelines. Reference the refrigerant piping software
pub # 32-3312-xx or refrigerant piping application guide SS-
APG006-xx for long line sets or specialty applications (xx denotes
latest revision).
(i)
Trane outdoor condensing units are factory charged with the system
charge required for the outdoor condensing unit and 15 feet of tested
connecting lines. If connecting line length exceeds 15 feet, then final
refrigerant charge adjustment is necessary. Each additional foot over
15 feet requires 0.6 ozs of refrigerant. See the Installer’s Guide for
full charging instructions.
