Mechanical Specification Options
GGeenneerraall
The Outdoor Units are fully charged from the factory
for up to 15 feet of piping. This unit is designed to
operate at outdoor ambient temperatures as high as
115°F. Cooling capacities are matched with a wide
selection of air handlers and furnace coils that are AHRI
certified. The unit is certified to UL 1995. Exterior is
designed for outdoor application.
CCaassiinngg
Unit casing is constructed of heavy gauge, galvanized
steel and painted with a weather-resistant powder paint
finish on all louvered panels and the fan top panel. The
corner panels are prepainted. All panels are subjected
to our 1,000 hour salt spray test . The base is made of a
CMBP-G30 weatherproof material to resist corrosion.
RReeffrriiggeerraanntt CCoonnttrroollss
Refrigeration system controls include condenser fan,
compressor contactor and high pressure switch. High
and low pressure controls are inherent to the
compressor. A factory supplied liquid line drier is
standard. Some models may require field installation.
CCoommpprreessssoorr
The compressor features internal over temperature,
pressure protection and total dipped hermetic motor.
Other features include: Centrifugal oil pump and low
vibration and noise.
CCoonnddeennsseerr CCooiill
The outdoor coil provides low airflow resistance and
efficient heat transfer. The coil is protected on all four
sides by louvered panels.
LLooww AAmmbbiieenntt CCoooolliinngg
As manufactured, this system has a cooling capacity to
55°F. The addition of an evaporator defrost control
permits operation to 40°F. The addition of an
evaporator defrost control with TXV permits low
ambient cooling to 30°F.
TThheerrmmoossttaattss—Cooling only and heat/cooling (manual
and automatic change over). Sub-base to match
thermostat and locking thermostat cover.
EEvvaappoorraattoorr DDeeffrroosstt CCoonnttrrooll — See Low Ambient
Cooling.
American Standard optimizes the performance of homes and buildings around the world. A business of Ingersoll Rand,
the leader in creating and sustaining safe, comfortable and energy efficient environments, American Standard offers a
broad portfolio of advanced controls and HVAC systems, comprehensive building services, and parts. For more
information, visit www.americanstandardair.com.
American Standard has a policy of continuous product and product data improvements and reserves the right to change design and specifications without notice.
©2016 American Standard Heating & Air Conditioning
4A6H5060H-SUB-1A-EN
10 Jun 2016
Supersedes (New)
