Trane BAYHTR1504BRKC User Manual

2
TEM6A0D60-SUB-1E-EN
Outline Drawing
NOTE: THIS UNIT IS APPROVED FOR INSTALLATION
CLEARANCES TO COMBUSTIBLE MATERIAL AS
STATED ON THE UNIT RATING NAMEPLATE
PRODUCT DIMENSIONS
Air Handler Model A B C D E F H
Flow
Control
Gas Line
Braze
TEM6A0D60H51SB 53.87 26.50 24.50 24.75 7.01 9.66 27.19 TXV
7/8
All dimensions are in inches
Page 14 of 20 10/16/2019
MOHS, PLANS EXAMINER
REV #1 .
2405 E AINSWORTH AVE B19-2396
INSTALL HVAC SYSTEM/PORT OF PASCO 10/1/2019

Trane BAYHTR1504BRKC Specifications

General

Brand	Trane
Model	BAYHTR1504BRKC
Category	Heater
Language	English
