Product Specifications
MODEL TEM6A0D60H51SB
RATED VOLTS/PH/HZ 208-230/1/60
RATINGS
(a)
See O.D. Specifications
INDOOR COIL — Type
Plate Fin
Rows — F.P.I. 4 - 16
Face Area (sq. ft.)
6.47
Tube Size (in.)
3/8
Refrigerant Control
TXV
Drain Conn. Size (in.)
(b)
3/4 NPT
DUCT CONNECTIONS See Outline Drawing
INDOOR FAN — Type
Centrifugal
Diameter-Width (In.)
11 X 11
No. Used 1
Drive - No. Speeds
Direct - 16
CFM vs. in. w.g.
See Fan Performance Table
No. Motors — H.P. 1 - 3/4
Motor Speed R.P.M.
Variable
Volts/Ph/Hz 208-230/1/60
F.L. Amps
6.8
FILTER
Filter Furnished?
(c)
No
REFRIGERANT R-410A
Ref. Line Connections Brazed
Coupling or Conn. Size —
in. Gas
7/8
Coupling or Conn. Size —
in. Liq.
3/8
DIMENSIONS H x W x D
Crated (In.)
55-3/8 x 30-1/2 x 25-1/2
Uncrated 53-7/8 x 26-1/2 x 21-1/8
WEIGHT
Shipping (Lbs.) / Net (Lbs.)
181/168
(a)
These Air Handlers are A.H.R.I certified with various Split System Air
Conditioners and Heat Pumps (AHRI STANDARD 210/240). Refer to
the Split System Outdoor Unit Product Data Guides for performance
data.
(b)
3/4” Male Plastic Pipe (Ref: ASTM 1785–76)
(c)
Remote filter required.
