Trane BAYHTR1504BRKC User Manual

4
TEM6A0D60-SUB-1E-EN
Minimum Airflow CFM
TEM6A0D60H51SB
Heater Minimum Heater Airflow CFM
With Heat Pump Without Heat Pump
BAYHTR1504BRK, BAYHTR1504LUG
BAYHTR1505BRK, BAYHTR1505LUG
1150 975
BAYHTR1508BRK, BAYHTR1508LUG
1150 975
BAYHTR1510BRK, BAYHTR1510LUG
1150 975
BAYHTR1517BRK
1300 1125
BAYHTR3510LUG
1150 975
BAYHTR3517LUG
1300 1125
BAYHTR1523BRK
1380 1125
BAYHTR1525BRK
1550 1345
TEM6A0D60H51SB Airflow Performance with Auxiliary Heat
Airflow Settings
Dip Switch Settings
Nominal Airflow
See following tables for
heater application:
- Pressure Drop for
Electrical Heaters
- Minimum Heating
Airflow Matrix (on unit
nameplates)
Switch 7 Switch 8
Low ON ON 997
Med-Lo OFF ON 1129
Med-Hi ON OFF 1350
High
OFF OFF 1597
Page 16 of 20 10/16/2019
MOHS, PLANS EXAMINER
REV #1 .
2405 E AINSWORTH AVE B19-2396
INSTALL HVAC SYSTEM/PORT OF PASCO 10/1/2019
