INSTALLER'S GUIDE
18-HB22D1-14
HEATER STAGING
The TEM/A4AH4 air handler families do not stage air flow in correlation with heater element staging. The minimum heating air flow table is representative for any call for
indoor heat.
BAYHTR ELECTRIC HEAT STAGE MATRIX
Model No.
BAYHTR1504BRK*
BAYHTR1504LUG*
BAYHTR1505BRK*
BAYHTR1505LUG*
BAYHTR1508BRK*
BAYHTR1508LUG*
BAYHTR1510BRK*
BAYHTR1510LUG*
BAYHTR1517BRK*
BAYHTR1523BRK*
BAYHTR1525BRK*
BAYHTR3510LUG*
BAYHTR3517LUG*
Electric Heat Stages 1 1 1 1 2 2 2 1 1
Stage 1 Capacity (kW) 3.84 4.8 7.68 9.6 9.6 9.6 12.0 9.6 14.4
Stage 2 Capacity (kW) 3.84 4.8 7.68 9.6 14.4 19.2 24.0 9.6 14.4
