Trane BAYLOAM105AA User Manual

2
Installer’s Guide
Figure 2. Identify Exterior Components
Compressor
Access Panel
Blower Access
Panel
Control/Heat
Box Access
Panel
4 Louvered Panels
(1 on each side)
Figure 1. Identify LOAM Kit Components
Note: Unit vents not
shown
Universal Bracket
Liquid Sensor Clamp
Bushing
Wire Nuts (5)
Cable Ties (5)
Liquid Sensor
Assembly
Thermal
Compound
Outdoor
Air Sensor
Retainer
Dart
Information
Label
Press Tight Insulating Tape
(sensor Insulation)
Low Voltage
Pigtail Assembly
Sheet Metal
Screw (5)
Outdoor Air Sensor
Control Module
Solid State
Relay (SSR)
Coil/Filter Access
Panel

Trane BAYLOAM105AA Specifications

General

Brand	Trane
Model	BAYLOAM105AA
Category	Control Unit
Language	English
