8
Installer’s Guide
Figure 9. Mount Outdoor Temperature Sensor
OUTDOOR
TEMPERATURE
SENSOR DART
OUTDOOR
TEMPERATURE
SENSOR WIRES
LIQUID LINE
SENSOR WIRES
LOUVERED PANEL REMOVE 3 SCREWS
LIFT PANEL UP TO UNHOOK FROM SLOT
REMOVE 8 FAN GRILL SCREWS
TO ROUTE OUTDOOR SENSOR WIRES
BEHIND COIL INTO COMPRESSOR AREA
