Page 4
INSTALLER’S GUIDE
1.80"
2.82"
Figure 4. Mount Mixed Air Sensor in Blower Compartment
View ‘A’ Approximate
Mounting Dimension
See View ‘A’
Mount the Mixed Air
Sensor to the partition
using two sheetmetal
screws. See View A
for approximate
positioning.
