Electrical data
NOMINAL VALUES
MAXIMUM VALUES
condenser water temperature in/out 30/35°C, evaporator water
temperature in/out 12/7°C
Model
Compressors
TOTAL
TOTAL
F.L.I.
F.L.A.
L.R.A.
F.L.I.
F.L.A.
S.A.
S.A. with
soft starter
F.L.I.
F.L.A.
S.A.
L.R.A.
with soft
starter
S.A. with
soft starter
kW
A
A
kW
A
A
A
kW
A
A
A
One refrigerant circuit sizes
050 11.7 20.4 142.0 11.7 20.4 152.2 81.2 26.9 47.0 164.0 71,0 93.0
055 13.5 23.7 147.0 13.5 23.7 158.9 85.4 29.7 52.0 169.0 73,5 95.5
065 15.5 27.2 147.0 15.5 27.2 160.6 87.1 33.7 59.0 176.0 73,5 102.5
075 19.3 33.7 197.0 19.3 33.7 213.9 115.4 39.2 68.6 227.0 98,5 128.5
085 20.7 36.2 197.0 20.7 36.2 215.1 116.6 44.1 77.2 235.6 98,5 137.1
100 24.9 43.5 197.0 24.9 43.5 218.8 120.3 51.2 89.6 235.6 98,5 137.1
115 28.1 49.2 215.0 28.1 49.2 239.6 132.1 58.3 102.0 248.0 107,5 140.5
130 31.2 54.6 260.0 31.2 54.6 287.3 157.3 64.6 113.0 311.0 130,0 181.0
140 34.3 60.1 260.0 34.3 60.1 290.0 160.0 70.9 124.0 322.0 130,0 192.0
150 39,9 69,9 320,0 39,9 69,9 355,0 195,0 80,6 141,0 382,0 160,0 222,0
170 44,6 78,1 320,0 44,6 78,1 359,0 199,0 90,3 158,0 399,0 160,0 239,0
190 49,6 86,7 344,0 49,6 86,7 409,0 237,0 105,7 185,0 423,0 172,0 251,0
210 55,8 97,6 344,0 55,8 97,6 417,2 245,2 121,1 212,0 450,0 172,0 278,0
Two refrigerant circuits sizes
095 25,6 44,7 147,0 25,6 44,7 180,6 107,1 56,6 99,0 216,0 73,5 142,5
105 27,5 48,1 147,0 27,5 48,1 183,0 109,5 59,4 104,0 221,0 73,5 147,5
120 30,3 53,1 147,0 30,3 53,1 186,8 113,3 67,4 118,0 235,0 73,5 161,5
135 34,5 60,4 158,0 34,5 60,4 203,3 124,3 74,3 130,0 253,0 79,0 174,0
160 42,2 73,8 197,0 42,2 73,8 252,4 153,9 88,2 154,4 312,8 98,5 214,3
185 49,5 86,6 215,0 49,5 86,6 279,9 172,4 102,4 179,2 343,2 107,5 235,7
215 57,8 101,2 215,0 57,8 101,2 290,9 183,4 116,6 204,0 368,0 107,5 260,5
235 62,5 109,4 260,0 62,5 109,4 342,1 212,1 129,1 226,0 424,0 130,0 294,0
255 68,7 120,2 260,0 68,7 120,2 350,2 220,2 141,7 248,0 446,0 130,0 316,0
295 78,5 137,4 320,0 78,5 137,4 423,1 263,1 161,1 282,0 523,0 160,0 363,0
325 90,3 158,0 320,0 90,3 158,0 438,5 278,5 180,6 316,0 557,0 160,0 397,0
365 99,1 173,5 344,0 99,1 173,5 474,1 302,1 211,4 370,0 608,0 172,0 436,0
420 111,5 195,1 344,0 111,5 195,1 490,3 318,3 242,3 424,0 662,0 172,0 490,0
485 132,7 232,2 320,0 132,7 232,2 513,5 353,5 270,9 474,0 715,0 160,0 555,0
540 145,2 254,2 344,0 145,2 254,2 555,8 383,8 301,7 528,0 766,0 172,0 594,0
580 153,5 268,6 344,0 153,5 268,6 567,8 395,8 332,6 582,0 820,0 172,0 648,0
620 166,0 290,5 344,0 166,0 290,5 586,0 414,0 363,4 636,0 874,0 172,0 702,0
Electrical data referred to 400V - 3Phases+N - 50Hz
Maximum operating admitted conditions: 10%
Maximum phase unbalance: 2%
F.L.I. = Full load electrical power
F.L.A. = Full load operating current
S.A. = Sum of compressor motor locked rotor current (L.R.A) of most powerful compressor plus F.L.A of other
compressor(s)
