CG-PRC026C-GB
14
General Data
Table 1 - CGAX Standard effi ciency and Standard Noise
Eurovent Performances (1)
CGAX
015
SE-SN
CGAX
017
SE-SN
CGAX
020
SE-SN
CGAX
023
SE-SN
CGAX
026
SE-SN
CGAX
030
SE-SN
CGAX
036
SE-SN
Net Cooling Capacity (kW) 43 49 59 65 74 82 99
Total Power input in cooling (kW) 15 17 19 22 26 29 33
Total Power input in cooling - HESP Option (100Pa) (kW) 15 18 21 24 27 31 34
EER 2.98 2.88 3.08 2.95 2.87 2.84 2.96
EER - HESP (915 RPM - 100Pa) 2.82 2.74 2.89 2.81 2.78 2.76 2.81
ESEER 3.89 3.93 3.81 3.82 3.84 3.80 3.93
Eurovent Effi ciency class Cooling BCBBCCB
Sound power level (dBA) 83 83 85 85 85 86 84
Sound power level - HESP Option (100Pa) (dBA) 85 85 89 89 89 89 89
Unit amps (4) (5)
Unit rated amps (A) 34 38 45 50 56 64 74
Unit rated amps - HESP Option (100Pa) (A) 35 39 47 52 57 66 75
Unit start up amps (A) 116 160 167 183 188 189 198
Unit start up amps - HESP Option (100Pa) (A) 117 161 169 185 190 191 199
Short Circuit Unit Capacity (9) (kA) 12 12 12 12 12 12 15
Compressor
Compressor Number per Circuit # 2222223
Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll
Model Circuit1 / Circuit 2 7.5+7.5 7.5+10 10+10 10+13 13+13 15+15 12+12+12
Motor RPM (rpm) 2900
Evaporator
Quantity # 1111111
Type Stainless steel Copper Brazed plate Heat exchanger
Evaporator model P80x66 P80x92 P80x92 P80x92 P120Tx76 P120Tx76 P120Tx104
Evaporator Water Content volume (l) 3.8 5.3 5.3 5.3 9.2 9.2 12.5
Nominal water connection size (Grooved coupling) -
Without HYM
(in) - (mm) 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3
Nominal water connection size (Grooved coupling) -
With HYM
(in) - (mm) 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3 3” OD - 76.1
Hydraulic Module Components
Expansion Tank Volume (l) 25 25 25 25 25 25 35
Max User water loop Volume for factory mounted
expansion tank (1)
(l) 1450 1450 1450 1450 1450 1450 2000
Optional water Buffer tank volume (l) 324 324 324 324 324 324 444
Max. Water-side Operating Pressure without pump
package
(kPa) 1000
Max. Water-side Operating Pressure with pump
package
(kPa) 400
Condenser
Type Full aluminum Micro channel heat exchanger
Quantity of coil # 1111112
Face area per circuit (m²) 2.23 2.23 2.96 2.96 2.96 2.96 4.46
Condenser Fan
Quantity # 1122222
Diameter (mm) 800
Fan / motor Type Propeller fan : Fixed speed AC motor / Variable speed - EC motor
Airfl ow per Fan (m
3
/h) 13788 13828 12362 12362 12370 12375 13827
Airfl ow per Fan - HESP Option (100Pa) (m
3
/h) 13753 13718 12248 12231 12211 12193 13727
Motor RPM (rpm) 686 686 686 686 686 686 686
Motor RPM - HESP Option (100Pa) (rpm) 915 915 915 915 915 915 915
Partial Heat recovery (PHR) option
Heat-Exchanger Type Stainless steel Copper Brazed plate Heat exchanger
Heat-Exchanger Model B3-014-14-4.5M B3-014-14-4.5M B3-014-14-4.5M B3-014-14-4.5M B3-027-14-4.5L B3-027-14-4.5L B3-027-14-4.5L
Water connection size (Thread connection) (in) - (mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
Water content volume (l) 0.14 0.14 0.14 0.14 0.35 0.35 0.35
Dimensions
Unit Length (mm) 2346 2346 2346 2346 2346 2346 2327
Unit Width (mm) 1285 1285 1285 1285 1285 1285 2250
Unit Height (mm) 1524 1524 1524 1524 1524 1524 1524
Option Additional height
Water Buffer tank option (mm) +330 +330 +330 +330 +330 +330 +330
Weights
Shipping Weight (5) (kg) 519 531 574 579 608 621 853
Operating Weight (5) (kg) 497 509 552 557 587 599 819
Option Additional shipping weight
Single pump - Standard head pressure (kg) 46 46 46 49 49 49 45
Single pump - High head pressure (kg) 51 51 51 51 51 51 49
Twin pump - Standard head pressure (kg) 70 70 70 75 75 75 71
Twin pump - High head pressure (kg) 82 82 82 82 82 82 86
Partial heat recovery option (kg) 1.48 1.48 1.48 1.48 3.82 3.82 3.82
Water Buffer tank option (kg) 319 319 319 319 319 319 425
System data
Nb of refrigerant circuit # 1111111
Minimum cooling load % (6) % 50 43 50 43 50 50 33
Standard unit
R410A refrigerant charge Circuit1 / Circuit 2 (kg) 7.5 9.0 9.0 9.0 10.5 10.5 14.0
Oil charge Circuit1 / Circuit 2 (l) 6.0 6.3 6.6 6.6 6.6 7.2 10.5
Unit with partial heat recovery option
R410a refrigerant charge Circuit1 / Circuit 2 (kg) 7.5 9.0 9.0 9.0 10.5 10.5 14.0
Oil charge Circuit1 / Circuit 2 (l) 6.0 6.3 6.6 6.6 6.6 7.2 10.5
POE Oil type OIL058E / OIL057E
(1) At Evaporator water temperature : 12°C / 7°C - Condenser air temperature 35°C according to EN14511:2013
(2) At Evaporator water temperature : 6.6°C (44°F) / 12.2°C (54°F) - condenser air temperature 46°C (114.8°F)
(4) under 400V/3/50Hz
(5) Rated Condition without Pump Package
(6) Percent minimum load can be lowered on demand to local sales offi ce.
(7) Minimum start-up/operation ambient based on a 2.22 m/s (5mph) wind across the condenser.
(8) Maximum ambient operation is for unit at 12°C / 7°C
(9) If the power line of the unit is protected by fuses gG of the same size as the disconnect switch.
Electrical & system data are subject to change without notice. Please refer to unit nameplate data.
