Electrical Data
Table 9 - CGAX - CXAX SE-SA-SN or LN Electrical Characteristics
Unit Type
Base unit amps at 400V / 3Ph / 50Hz
Max Power
input
(kW)
Max Amps
(A)
Start up amp
Power
Factor
Without soft
starter (A)
With soft
starter (A)
CGAX - CXAX 015 SE-SA-SN or LN 19.4 33.8 116.3 77.1 0.85
CGAX - CXAX 017 SE-SA-SN or LN 22.1 38.5 160.3 103.5 0.85
CGAX - CXAX 020 SE-SA-SN or LN 25.8 45.4 167.2 110.4 0.84
CGAX - CXAX 023 SE-SA-SN or LN 29.5 50.5 183.2 120.0 0.86
CGAX - CXAX 026 SE-SA-SN or LN 33.3 55.6 188.3 125.1 0.88
CGAX - CXAX 030 SE-SA-SN or LN 37.0 64.0 189.5 127.5 0.85
CGAX - CXAX 036 SE-SA-SN or LN 43.0 73.8 197.9 139.1 0.85
CGAX - CXAX 039 SE-SA-SN or LN 49.0 81.0 213.7 150.5 0.89
CGAX - CXAX 045 SE-SA-SN or LN 55.5 95.8 221.3 159.3 0.85
CGAX - CXAX 035 SE-SA-SN or LN 44.2 76.5 198.3 141.5 0.85
CGAX - CXAX 040 SE-SA-SN or LN 51.6 90.4 212.2 155.4 0.84
CGAX - CXAX 046 SE-SA-SN or LN 59.0 100.6 233.3 170.1 0.86
CGAX - CXAX 052 SE-SA-SN or LN 66.5 110.8 243.5 180.3 0.88
CGAX - CXAX 060 SE-SA-SN or LN 74.0 127.6 253.1 191.1 0.85
Table 10 - CGAX - CXAX SE-LA-SN or LN Electrical Characteristics
Unit Type
Base unit amps at 400V / 3Ph / 50Hz
Max Power
input
(kW)
Max Amps
(A)
Start up amp
Power
Factor
Without soft
starter (A)
With soft
starter (A)
CGAX - CXAX 015 SE-LA-SN or LN 20.4 34.5 117.0 77.8 0.87
CGAX - CXAX 017 SE-LA-SN or LN 23.2 39.2 161.0 104.2 0.87
CGAX - CXAX 020 SE-LA-SN or LN 26.8 46.2 168.0 111.2 0.85
CGAX - CXAX 023 SE-LA-SN or LN 30.6 51.3 184.0 120.8 0.88
CGAX - CXAX 026 SE-LA-SN or LN 34.3 56.4 189.1 125.9 0.89
CGAX - CXAX 030 SE-LA-SN or LN 38.1 64.8 190.3 128.3 0.86
CGAX - CXAX 036 SE-LA-SN or LN 44.1 74.6 198.7 139.9 0.86
CGAX - CXAX 039 SE-LA-SN or LN 50.0 81.8 214.5 151.3 0.89
CGAX - CXAX 045 SE-LA-SN or LN 56.6 96.6 222.1 160.1 0.85
CGAX - CXAX 035 SE-LA-SN or LN 46.4 78.1 199.9 143.1 0.87
CGAX - CXAX 040 SE-LA-SN or LN 53.7 91.9 213.7 156.9 0.85
CGAX - CXAX 046 SE-LA-SN or LN 61.2 102.1 234.8 171.6 0.88
CGAX - CXAX 052 SE-LA-SN or LN 68.6 112.3 245.0 181.8 0.89
CGAX - CXAX 060 SE-LA-SN or LN 76.1 129.1 254.6 192.6 0.86
SE = Standard Effi ciency
SA = Standard Ambient
LA = Low Ambient
SN = Standard Noise
LN = Low Noise
