Trane CGAX/CXAX User Manual

CG-PRC026C-GB
34
Electrical Data
Table 11 - CGAX - CXAX HESP Electrical Characteristics / CGAX - CXAX HE Electrical Characteristics
Unit Type
Base unit amps at 400V / 3Ph / 50Hz
Max Power
input
(kW)
Max Amps
(A)
Start up amp
Power
Factor
Without soft
starter (A)
With soft
starter (A)
CGAX - CXAX 015 HE or HESP 20.4 34.5 117.0 77.8 0.87
CGAX - CXAX 017 HE or HESP 23.2 39.2 161.0 104.2 0.87
CGAX - CXAX 020 HE or HESP 27.9 46.9 168.7 111.9 0.87
CGAX - CXAX 023 HE or HESP 31.6 52.0 184.7 121.5 0.89
CGAX - CXAX 026 HE or HESP 35.4 57.1 189.8 126.6 0.90
CGAX - CXAX 030 HE or HESP 39.1 65.5 191.0 129.0 0.87
CGAX - CXAX 036 HE or HESP 45.1 75.4 199.5 140.7 0.87
CGAX - CXAX 039 HE or HESP 51.1 82.6 215.3 152.1 0.90
CGAX - CXAX 045 HE or HESP 58.7 98.2 223.7 161.7 0.87
CGAX - CXAX 035 HE or HESP 46.4 78.1 199.9 143.1 0.87
CGAX - CXAX 040 HE or HESP 55.8 93.5 215.3 158.5 0.87
CGAX - CXAX 046 HE or HESP 63.3 103.7 236.4 173.2 0.89
CGAX - CXAX 052 HE or HESP 70.7 113.9 246.6 183.4 0.90
CGAX - CXAX 060 HE or HESP 78.2 130.7 256.2 194.2 0.87
HE = High Effi ciency
HESP = High External Static Pressure
Table 12 - CGAX - CXAX Compressor electrical data
Unit Type
Compressor
Circuit 1 Circuit 2
Max
Power input
(kW)
Max
Amps
(A)
Start up
amp
(A)
Max
Power input
(kW)
Max
Amps
(A)
Start up
amp
(A)
CGAX - CXAX 015 9.2/9.2 15.5/15.5 98/98 0/0 0/0 0/0
CGAX - CXAX 017 9.2/12 15.5/20.2 98/142 0/0 0/0 0/0
CGAX - CXAX 020 12/12 20.2/20.2 142/142 0/0 0/0 0/0
CGAX - CXAX 023 12/15.7 20.2/25.3 142/158 0/0 0/0 0/0
CGAX - CXAX 026 15.7/15.7 25.3/25.3 158/158 0/0 0/0 0/0
CGAX - CXAX 030 17.6/17.6 29.5/29.5 155/155 0/0 0/0 0/0
CGAX - CXAX 036 13.7/13.7/13.7 22.9/22.9/22.9 147/147/147 0/0 0/0 0/0
CGAX - CXAX 039 15.7/15.7/15.7 25.3/25.3/25.3 158/158/158 0/0 0/0 0/0
CGAX - CXAX 045 17.6/17.6/17.6 29.5/29.5/29.5 155/155/155 0/0 0/0 0/0
CGAX - CXAX 035 9.2/12 15.5/20.2 98/142 9.2/12 15.5/20.2 98/142
CGAX - CXAX 040 12/12 20.2/20.2 142/142 12/12 20.2/20.2 142/142
CGAX - CXAX 046 12/15.7 20.2/25.3 142/158 12/15.7 20.2/25.3 142/158
CGAX - CXAX 052 15.7/15.7 25.3/25.3 158/158 15.7/15.7 25.3/25.3 158/158
CGAX - CXAX 060 17.6/17.6 29.5/29.5 155/155 17.6/17.6 29.5/29.5 155/155
