CG-PRC026C-GB
22
General Data
Table 5 - CXAX Standard effi ciency and Standard Noise
Eurovent Performances (1)
CXAX
015
SE-SN
CXAX
017
SE-SN
CXAX
020
SE-SN
CXAX
023
SE-SN
CXAX
026
SE-SN
CXAX
030
SE-SN
CXAX
036
SE-SN
Net Cooling Capacity (kW) 42 48 56 65 72 79 94
Total Power input in cooling (kW) 14 17 19 22 25 28 32
Total Power input in cooling - HESP Option (100Pa) (kW) 15 17 20 24 27 30 34
EER 2.90 2.83 2.91 2.97 2.84 2.84 2.90
EER - HESP Option (100Pa) 2.80 2.76 2.73 2.71 2.63 2.62 2.78
ESEER 3.71 3.75 3.63 3.80 3.84 3.82 3.96
Eurovent Effi ciency class Cooling BCBBCCB
Sound power level (dBA) 84 84 85 85 85 86 86
Sound power level - HESP Option (100Pa) (dBA) 86 86 89 92 94 89 95
Heating application data (2)
Net Heating Capacity (A) 43 51 57 63 69 78 96
Total Power input in heating (A) 14 16 19 21 23 25 30
Total Power input in heating - HESP Option (100Pa) (A) 15 17 21 23 26 27 32
COP (A) 3.09 3.15 2.98 3.08 3.01 3.09 3.19
COP - HESP Option (100Pa) 2.87 2.97 2.71 2.75 2.67 2.89 3.01
Eurovent Effi ciency class Heating B B C B B B B
ηs 126 125 115 124 125 124 128
SCOP (kA) 3.21 3.21 2.95 3.17 3.19 3.18 3.29
Unit amps (4) (5)
Unit rated amps (A) 34 38 45 50 56 64 74
Unit rated amps - HESP Option (100Pa) (A) 35 39 47 52 57 66 75
Unit start up amps (A) 116 160 167 183 188 189 198
Unit start up amps - HESP Option (100Pa) (A) 117 161 169 185 190 191 199
Short Circuit Unit Capacity (9) (kA) 12 12 12 12 12 12 15
Compressor
Compressor Number per Circuit # 2 2 2 2 2 2 3
Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll
Model Circuit1 / Circuit 2 7.5+7.5 7.5+10 10+10 10+13 13+13 15+15 12+12+12
Motor RPM (rpm) 2900
Evaporator
Quantity #1111111
Type Stainless steel Copper Brazed plate Heat exchanger
Evaporator model P80x78 P80x78 P80x78 P120Tx86 P120Tx86 P120Tx86 P120Tx110
Evaporator Water Content volume (l) 4.5 4.5 4.5 10.4 10.4 10.4 13.3
Nominal water connection size (Grooved coupling) - Without HYM (in) - (mm) 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3
Nominal water connection size (Grooved coupling) - With HYM (in) - (mm) 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3 2” - 60.3 3” OD - 76.1
Hydraulic Module Components
Expansion Tank Volume (l) 25 25 25 25 25 25 35
Max User water loop Volume for factory mounted expansion tank (1) (l) 1450 1450 1450 1450 1450 1450 2000
Optional water Buffer tank volume (l) 324 324 324 324 324 324 444
Max. Water-side Operating Pressure without pump package (kPa) 1000
Max. Water-side Operating Pressure with pump package (kPa) 400
Condenser
Type Aluminum fi ns & copper tubes heat exchanger
Quantity of coil # 1 1 1 1 1 1 2
Face area per circuit (m²) 2.96 2.96 2.96 2.96 2.96 3.46 5.93
Condenser Fan
Quantity #1122222
Diameter (mm) 800
Fan / motor Type Propeller fan : Fixed speed AC motor / Variable speed - EC motor / HESP MAX SPEED
Airfl ow per Fan (m
3
/h) 14949 14960 14966 12721 12726 13352 14959
Airfl ow per Fan - HESP Option (100Pa) (m
3
/h) 15048 15018 14972 12622 12608 13258 15019
Motor RPM (rpm) 686 686 686 686 686 686 686
Motor RPM - HESP Option (100Pa) (rpm) 915 915 915 915 915 915 915
Partial Heat recovery (PHR) option
Heat-Exchanger Type Stainless steel Copper Brazed plate Heat exchanger
Heat-Exchanger Model B3-014-14-4.5M B3-014-14-4.5M B3-014-14-4.5M B3-014-14-4.5M B3-027-14-4.5L B3-027-14-4.5L B3-027-14-4.5L
Water connection size (Thread connection) (in) - (mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
Water content volume (l) 0.14 0.14 0.14 0.14 0.35 0.35 0.35
Dimensions
Unit Length (mm) 2346 2346 2346 2346 2346 2346 2327
Unit Width (mm) 1285 1285 1285 1285 1285 1285 2250
Unit Height (mm) 1524 1524 1524 1524 1524 1724 1524
Option Additional height
Water Buffer tank option (mm) +330 +330 +330 +330 +330 +330 +330
Weights
Shipping Weight (5) (kg) 558 564 616 644 649 684 911
Operating Weight (5) (kg) 539 545 596 624 630 665 881
Option Additional shipping weight
Single pump - Standard head pressure (kg) 46 46 46 49 49 49 45
Single pump - High head pressure (kg) 51 51 51 51 51 51 49
Twin pump - Standard head pressure (kg) 70 70 70 75 75 75 71
Twin pump - High head pressure (kg) 82 82 82 82 82 82 86
Partial heat recovery option (kg) 1.48 1.48 1.48 1.48 3.82 3.82 3.82
Water Buffer tank option (kg) 319 319 319 319 319 319 425
System data
Nb of refrigerant circuit # 1 1 1 1 1 1 1
Minimum cooling load % (6) % 50 43 50 43 50 50 33
Standard unit
R410A refrigerant charge Circuit1 / Circuit 2 (kg) 12.5 13.0 15.0 15.0 15.0 15.5 26.0
Oil charge Circuit1 / Circuit 2 (l) 6.0 6.3 6.6 6.6 6.6 7.2 10.5
Unit with partial heat recovery option
R410a refrigerant charge Circuit1 / Circuit 2 (kg) 12.5 13.0 15.0 15.0 15.0 15.5 26.0
Oil charge Circuit1 / Circuit 2 (l) 6.0 6.3 6.6 6.6 6.6 7.2 10.5
POE Oil type OIL058E / OIL057E
(1) At Evaporator water temperature : 12°C / 7°C - Condenser air temperature 35°C according to EN14511:2013
(2) At Evaporator water temperature : 40°C / 45°C - Condenser air. DB/WB 7°C / 6°C according to EN14511:2013
(4) under 400V/3/50Hz
(5) Rated Condition without Pump Package
(6) Minimum ambient in heating operation is for unit at 40°C / 45°C
(7) Minimum start-up/operation ambient based on a 2.22 m/s (5mph) wind across the condenser.
(8) Maximum ambient operation is for unit at 12°C / 7°C
(9) If the power line of the unit is protected by fuses gG of the same size as the disconnect switch.
Electrical & system data are subject to change without notice. Please refer to unit nameplate data.
