CG-PRC026C-GB
29
General Data
Table 8 - CXAX High Effi ciency and Low Noise (continued)
Eurovent Performances (1)
CXAX
015
HE-LN
CXAX
017
HE-LN
CXAX
020
HE-LN
CXAX
023
HE-LN
CXAX
026
HE-LN
CXAX
030
HE-LN
CXAX
036
HE-LN
Net Cooling Capacity (kW) 108 118 94 114 127 146 162
Total Power input in cooling (kW) 36 41 34 37 43 49 55
EER 3.00 2.88 2.81 3.06 2.96 2.95 2.93
ESEER 4.20 4.02 3.98 4.10 4.00 4.03 3.95
Eurovent Effi ciency class Cooling BCCBBBB
Sound power level (dBA) 81 82 81 84 83 83 84
Heating application data (2)
Net Heating Capacity (kW) 110 120 101 114 127 139 162
Total Power input in heating (kW) 35 39 32 37 42 46 52
COP 3.14 3.12 3.16 3.08 3.02 3.00 3.11
Eurovent Effi ciency class Heating B B B B B B B
ηs (%) 133 132 131 124 124 128 129
SCOP 3.39 3.37 3.35 3.16 3.16 3.28 3.30
Unit amps (4) (5)
Unit rated amps (A) 86 98 78 93 104 114 131
Unit rated amps - HESP (A) 86 98 78 93 104 114 131
Unit start up amps (A) 218 224 200 215 236 247 256
Unit start up amps - HESP (A) 218 224 200 215 236 247 256
Short Circuit Unit Capacity (9) (kA) 15 15 15 15 15 15 15
Compressor
Compressor Number per Circuit # 3 3 2 2 2 2 2
Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll
Model Circuit1 / Circuit 2 13+13+13 15+15+15
7.5+10 /
7.5+10
10+10 / 10+10 10+13 /10+13 13+13 / 13+13 15+15 / 15+15
Rated Amps Circuit1 / Circuit 2 (4) (A)
25.3+25.3+
25.3
29.5+29.5+
29.5
15.5 / 20.2 /
15.5+20.2
20.2 / 20.2 /
20.2+20.2
20.2 / 25.3 /
20.2+25.3
25.3 / 25.3 /
25.3+25.3
29.5 / 29.5 /
29.5+29.5
Locked Rotor Amps Circuit1 / Circuit 2 (4) (A) 158+158 +158 155+155 +155
98 / 142 /
98+142
142 / 142 /
142+142
142 / 158 /
142+158
158 / 158 /
158+158
155 / 155 /
155+155
Motor RPM (rpm) 2900
Oil sump heater Circuit1 / Circuit 2 (W) 0.25 / 0 0.25 / 0 0.17 / 0.17 0.17 / 0.17 0.17 / 0.17 0.17 / 0.17 0.17 / 0.17
Evaporator
Quantity #1111111
Type Stainless steel Copper Brazed plate Heat exchanger
Evaporator model P120Tx110 P120Tx110 DP300x82 DP300x82 DP300x82 DP300x114 DP300x114
Evaporator Water Content volume (l) 13.3 13.3 8.5 8.5 8.5 11.8 11.8
Nominal water connection size (Grooved coupling) - Without HYM (in) - (mm) 2” - 60.3 2” - 60.3 3” OD - 76.1 3” OD - 76.1 3” OD - 76.1 3” OD - 76.1 3” OD - 76.1
Nominal water connection size (Grooved coupling) - With HYM
(in) - (mm) 3” OD - 76.1 3” OD - 76.1 3” OD - 76.1 3” OD - 76.1 3” OD - 76.1 3” OD - 76.1 3” OD - 76.1
Hydraulic Module Components
Expansion Tank Volume (l) 35 35 35 35 35 35 35
Max User water loop Volume for factory mounted expansion tank (1) (l) 2000 2000 2000 2000 2000 2000 2000
Optional water Buffer tank volume (l) 444 444 444 444 444 444 444
Max. Water-side Operating Pressure without pump package (kPa) 1000
Max. Water-side Operating Pressure with pump package (kPa) 400
Condenser
Type Aluminum fi ns & copper tubes heat exchanger
Quantity of coil # 2 2 2 2 2 2 2
Face area per circuit (m²) 5.93 5.93 2.96 2.96 2.96 2.96 3.46
Condenser Fan
Quantity #3324444
Diameter (mm) 800
Fan / motor Type Propeller fan : Variable speed - EC motor
Airfl ow per Fan (m
3
/h) 13823 13828 14960 14964 12725 12725 13351
Motor RPM (rpm) 150 - 686 RPM
Partial Heat recovery (PHR) option
Heat-Exchanger Type Stainless steel Copper Brazed plate Heat exchanger
Heat-Exchanger Model B3-027-20-4.5L B3-027-20-4.5L 2x B3-014-14-4.5M 2x B3-014-14-4.5M 2x B3-014-14-4.5M 2x B3-027-14-4.5L 2x B3-027-14-4.5L
Water connection size (Thread connection) (in) - (mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
G 1”1/4
(31.75 mm)
Water content volume (l) 0.5 0.5 2x0.14 2x0.14 2x0.14 2x0.35 2x0.35
Dimensions
Unit Length (mm) 2327 2327 2327 2327 2327 2327 2327
Unit Width (mm) 2250 2250 2250 2250 2250 2250 2250
Unit Height (mm) 1747 1747 1747 1747 1747 1747 1947
Option Additional height
Water Buffer tank option (mm) +330 +330 +330 +330 +330 +330 +330
Weights
Shipping Weight (5) (kg) 954 972 1000 1098 1098 1120 1190
Operating Weight (5) (kg) 925 942 974 1072 1072 1093 1163
Option Additional shipping weight
Single pump - Standard head pressure (kg) 47 47 45 47 47 47 47
Single pump - High head pressure (kg) 49 49 49 49 49 49 49
Twin pump - Standard head pressure (kg) 75 75 75 75 75 75 75
Twin pump - High head pressure (kg) 86 86 84 84 84 84 84
Partial heat recovery option (kg) 4.6 4.6 2x1.48 2x1.48 2x1.48 2x3.82 2x3.82
Water Buffer tank option (kg) 425 425 425 425 425 425 425
System data
Nb of refrigerant circuit # 1 1 2 2 2 2 2
Minimum cooling load % (6) % 33 33 22 25 22 25 25
Standard unit
R410A refrigerant charge Circuit1 / Circuit 2 (kg) 26.0 26.0 13.0 / 13.0 13.5 / 13.5 13.0 / 13.0 13.5 / 13.5 14.5 / 14.5
Oil charge Circuit1 / Circuit 2 (l) 10.5 11.5 6.3 / 6.3 6.6 / 6.6 6.6 / 6.6 6.6 / 6.6 7.2 / 7.2
Unit with partial heat receovery option
R410a refrigerant charge Circuit1 / Circuit 2 (kg) 26.0 26.0 13.0 / 13.0 13.5 / 13.5 13.0 / 13.0 13.5 / 13.5 14.5 / 14.5
Oil charge Circuit1 / Circuit 2 (l) 10.5 11.5 6.3 / 6.3 6.6 / 6.6 6.6 / 6.6 6.6 / 6.6 7.2 / 7.2
POE Oil type OIL058E / OIL057E
(1) At Evaporator water temperature : 12°C / 7°C - Condenser air temperature 35°C according to EN14511:2013
(2) At Evaporator water temperature : 40°C / 45°C - Condenser air. DB/WB 7°C/6°C according to EN14511:2013
(4) under 400V/3/50Hz
(5) Rated Condition without Pump Package
(6) Minimum ambient in heating operation is for unit at 40°C / 45°C
(7) Minimum start-up/operation ambient based on a 2.22 m/s (5mph) wind across the condenser.
(8) Maximum ambient operation is for unit at 12°C / 7°C
(9) If the power line of the unit is protected by fuses gG of the same size as the disconnect switch.
Electrical & system data are subject to change without notice. Please refer to unit nameplate data.
