Table of Contents
CG-PRC026C-GB
3
Introduction ....................................................................................................... 2
Features and Benefi ts ........................................................................................ 4
Application Considerations .............................................................................. 7
Unit Placement ................................................................................................ 10
Model Number Description ............................................................................12
General Data .................................................................................................... 14
Dimensional Data ............................................................................................ 30
Electrical Data .................................................................................................. 33
Hydraulic Data .................................................................................................. 37
Sound Data ......................................................................................................40
Typical Unit Schematics .................................................................................. 45
Mechanical Specifi cations .............................................................................. 48
Options ............................................................................................................. 50
