Electrical Data
Table 15 - CGAX-CXAX HE or HESP Condenser fans Electrical Data
Unit Type
Condenser fan
Circuit 1 (Fan 1 / 2 / 3) Circuit 2 (Fan 1 / 2)
Max
Power input (kW)
Max
Amps
(A)
Max
Power input (kW)
Max
Amps
(A)
CGAX-CXAX 015 HE or HESP 1.95/0/0 3/0/0 0/0 0/0
CGAX-CXAX 017 HE or HESP 1.95/0/0 3/0/0 0/0 0/0
CXAX 020 HE or HESP 1.95/0/0 3/0/0 0/0 0/0
CGAX 020 HE or HESP 1.95/1.95/0 3/3/0 0/0 0/0
CGAX-CXAX 023 HE or HESP 1.95/1.95/0 3/3/0 0/0 0/0
CGAX-CXAX 026 HE or HESP 1.95/1.95/0 3/3/0 0/0 0/0
CGAX-CXAX 030 HE or HESP 1.95/1.95/0 3/3/0 0/0 0/0
CGAX-CXAX 036 HE or HESP 1.95/1.95/0 3/3/0 0/0 0/0
CGAX 039 HE or HESP 1.95/1.95/0 3/3/0 0/0 0/0
CXAX 039 HE or HESP 1.95/1.95/1.95 3/3/3 0/0 0/0
CGAX-CXAX 045 HE or HESP 1.95/1.95/1.95 3/3/3 0/0 0/0
CGAX-CXAX 035 HE or HESP 1.95/0 3/0 1.95/0 3/0
CXAX 040 HE or HESP 1.95/0 3/0 1.95/0 3/0
CGAX 040 HE or HESP 1.95/1.95 3/3 1.95/1.95 3/3
CGAX-CXAX 046 HE or HESP 1.95/1.95 3/3 1.95/1.95 3/3
CGAX-CXAX 052 HE or HESP 1.95/1.95 3/3 1.95/1.95 3/3
CGAX-CXAX 060 HE or HESP 1.95/1.95 3/3 1.95/1.95 3/3
HE = High Effi ciency
HESP = High External Static Pressure
Table 16 - CGAX - CXAX Options electrical data
Unit Type
Disconnect
switch option
Pump package Heaters
Discon-
nect
switch
Power
Cable
cross
section
Single & Twin
pump
Standard head
pressure
Single & Twin
pump
High head
pressure
Freeze
protection
Without pump
package
Freeze
protection
With pump
package
Oil sump heater
Circuit 1 / 2
Size
(A)
Max
(mm²)
Max
Power
input
(kW)
Max
Amps
(A)
Max
Power
input
(kW)
Max
Amps
(A)
Max
Power
input
(W)
Max
Amps
(A)
Max
Power
input
(W)
Max
Amps
(A)
Max
Power
input
(kW)
Max
Amps
(A)
CGAX - CXAX 015 80 35 1.2 2.4 2.3 5.0 120 0.3 280 0.7 167 0.4
CGAX - CXAX 017 80 35 1.2 2.4 2.3 5.0 120 0.3 280 0.7 167 0.4
CGAX - CXAX 020 100 35 1.2 2.4 2.3 5.0 120 0.3 280 0.7 167 0.4
CGAX - CXAX 023 100 35 1.5 3.5 2.3 5.0 120 0.3 280 0.7 167 0.4
CGAX - CXAX 026 100 35 1.5 3.5 2.3 5.0 120 0.3 280 0.7 167 0.4
CGAX - CXAX 030 100 35 1.5 3.5 2.3 5.0 120 0.3 280 0.7 167 0.4
CGAX - CXAX 036 250 150 1.5 3.5 3.0 6.2 180 0.5 340 0.9 251 0.6
CGAX - CXAX 039 250 150 2.3 5.0 3.0 6.2 180 0.5 340 0.9 251 0.6
CGAX - CXAX 045 250 150 2.3 5.0 3.0 6.2 180 0.5 340 0.9 251 0.6
CGAX - CXAX 035 250 150 1.5 3.5 3.0 6.2 120 0.3 280 0.7 334 / 334 0.8 / 0.8
CGAX 040 250 150 2.3 5.0 3.0 6.2 120 0.3 280 0.7 334 / 334 0.8 / 0.8
CXAX 040 250 150 2.3 5.0 3.0 6.2 180 0.3 340 0.7 334 / 334 0.8 / 0.8
CGAX - CXAX 046 250 150 2.3 5.0 3.0 6.2 120 0.3 280 0.7 334 / 334 0.8 / 0.8
CGAX - CXAX 052 250 150 2.3 5.0 3.0 6.2 180 0.5 340 0.9 334 / 334 0.8 / 0.8
CGAX - CXAX 060 250 150 2.3 5.0 3.0 6.2 180 0.5 340 0.9 334 / 334 0.8 / 0.8
