Type of Requirement
Trane Supplied
Trane Installed
Trane Supplied
Field Installed
Field Supplied
Field Installed
Relief
• Rupture disk assembly
• RuptureGuard™
(optional); refer to
Installation, Operation,
and Maintenance:
RuptureGuard Pressure
Relief System Option
(CTV-SVX06*-EN)
• Vent line and flexible connector and vent line from
rupture disk to atmosphere
Insulation
• Insulation (optional)
• Insulation
• Chiller feet insulation
Water Piping Connection
Components
Flanged (optional)
• Welded on flange for
300 psig (2068.4 kPaG)
waterboxes
Flanged (optional)
• Victaulic® to flange
adapter for 150 psig
(1034.2 kPaG)
waterboxes
Victaulic®
• Victaulic® coupling for 150 psig (1034.2 kPaG) and
300 psig (2068.4 kPaG) waterboxes
• Fasteners for flanged-type connections (optional)
Other Materials
• Trace gas (1 lb [0.45 kg] maximum per machine as
needed to perform leak testing)
• Dry nitrogen (8 psig [55.2 kPaG] maximum per
machine as needed)
“CenTraVac™ Chiller
Installation Completion
and Request for Trane
Service,” p. B–1 (CTV-
ADF001*-EN; refer to
“Forms and Check
Sheets,” p. A–1)
• To be completed by installing contractor prior to
contacting Trane for start-up
Chiller start-up
commissioning
(a)
• Trane, or an agent of
Trane specifically
authorized to perform
start-up of Trane®
products
Post-commissioning
transport of empty
refrigerant containers for
return or recycling
• Move empty refrigerant containers to an easily
accessible point of loading
(a)
Start-up must be performed by Trane or an agent of Trane specifically authorized to perform start-up and warranty of Trane® products. Contractor shall
provide Trane (or an agent of Trane specifically authorized to perform start-up) with notice of the scheduled start-up at least two weeks prior to the
scheduled start-up.
Storage Requirements
NNOOTTIICCEE
IInnssuullaattiioonn DDaammaaggee!!
FFaaiilluurree ttoo ffoollllooww tthheessee iinnssttrruuccttiioonnss ccoouulldd rreessuulltt iinn
iinnssuullaattiioonn ddaammaaggee..
TToo pprreevveenntt ddaammaaggee ttoo ffaaccttoorryy iinnssttaalllleedd iinnssuullaattiioonn::
•• DDoo nnoott aallllooww tthhee iinnssuullaattiioonn ttoo bbee eexxppoosseedd ttoo
eexxcceessssiivvee ssuunnlliigghhtt.. SSttoorree iinnddoooorrss oorr ccoovveerr wwiitthh
ccaannvvaass ttoo pprreevveenntt eexxppoossuurree..
•• DDoo nnoott uussee tthhiinnnneerrss aanndd ssoollvveennttss oorr ootthheerr ttyyppeess
ooff ppaaiinntt.. UUssee oonnllyy wwaatteerr bbaassee llaatteexx..
Less than 1 month 1–6 months Greater than 6 months
Location requirements:
• Solid foundation
• Vibration free
• Dry
• Temperature range -40°F to 158°F
(-40°C to 70°C)
Location requirements:
• Solid foundation
• Vibration free
• Dry
• Temperature range -40°F to 158°F
(-40°C to 70°C)
Location requirements:
• Solid foundation
• Vibration free
• Dry
• Temperature range -40°F to 158°F
(-40°C to 70°C)
• Do not remove any plastic coverings • Do not remove any plastic coverings • Do not remove any plastic coverings
• Do not charge the chiller with refrigerant
• If additional refrigerant is on site, follow
manufacturer’s storage requirements
• Do not charge the chiller with refrigerant
• If additional refrigerant is on site, follow
manufacturer’s storage requirements
• Do not charge the chiller with refrigerant
• If additional refrigerant is on site, follow
manufacturer’s storage requirements
