CVHE-SVX02M-EN
17
Table 2. Representative weights, 60 Hz chillers (lb) (continued)
Model
Comp Size
CPKW
Evap Size
Cond Size
Weights without Starters Weights with Starters
NTON EVSZ CDSZ
Operating Shipping Operating Shipping
350–570 588 080S 080L 32131 27318 33811 28998
350–570 588 080L 080L 34319 28855 35999 30535
350–910 957 080S 080S 32843 28385 35843 31385
350–910 957 080S 080L 34481 29668 37481 32668
350–910 957 080L 080L 36669 31205 39669 34205
350–910 957 080L 142L 44814 37663 47814 40663
350–910 957 142M 142L 48446 40540 51446 43540
350–910 957 142L 142L 49667 41453 52667 44453
1070–1300 1062 080L 142L 45710 38559 48710 41559
1070–1300 1062 142M 142L 49116 41210 52116 44210
1070–1300 1062 142L 142L 50337 42123 53337 45123
1070–1300 1062 142E 142L 51762 43109 54762 46109
1070–1300 1062 142M 210L 55062 46057 58062 49057
1070–1300 1062 142L 210L 56333 46970 59333 49970
1070–1300 1062 142E 210L 57758 47956 60758 50956
1070–1300 1062 210L 210L 61899 51929 64899 54929
1070–1300 1062 250E 250L 76152 63330 79152 66330
1470 1340 210L 210L 64550 54580 67550 57580
1470–1720 1340 142L 210L 58984 49621 61984 52621
1470–1720 1340 250E 250L 78803 65981 81803 68981
Notes:
1. TECU tubes, 0.028 in. tube wall thickness.
2. 300 psig marine waterboxes.
3. Heaviest possible bundle and motor combination.
4. Operating weights assume the largest possible refrigerant charge.
5. Weights with starters assume the heaviest possible starter (AFD when it’s an allowed option).
6. Industrial Control Panel (INDP) option, add 50 lb.
7. Control Power Transformer (CPTR) option, add 130 lb.
8. Supplemental Motor Protection (SMP) option, add 500 lb.
Table 3. Representative weights, 50 Hz chillers (lb)
Model
Comp Size
CPKW
Evap Size
Cond Size
Weights without Starters Weights with Starters
NTON EVSZ CDSZ
Operating Shipping Operating Shipping
CVHE
190–320
215
032S 032S
14785 13426 — —
231 — — 16456 15097
190–320
215
032S 032L
15390 13881 — —
231 — — 17061 15552
190–320
215
032L 032L
16234 14531 — —
231 — — 17905 16202
190–320
215
050S 050S
19696 17195 — —
231 — — 21419 18918
190–320
215
050S 050L
20712 17952 — —
231 — — 22435 19675
190–320
215
050L 050L
21829 18682 — —
231 — — 23636 20502
300–500 360 050S 050S 21307 18806 — —
UUnniitt CClleeaarraanncceess aanndd WWeeiigghhttss
