18 Direct-Fired Make-up Air • MUA-SVX01A-EN
General Information
Vertical Configurations
(DFOA only)
For all arrangements shown, the gas piping and controls are on the near side.
Selected vertical units are available with special options — steam and electric
coils, no burner section.
Figure 2. Vertical configuration DFOA only
Fan Arrangement #4
Side Discharge
Fan Arrangement #6
Side Discharge
