Trane DFOA - Installation; Figure 13. DFOA Roof Curb Models 215-230

MUA-SVX01A-EN • Direct-Fired Make-up Air 33
Installation
Note: Curb to be shipped loose and assembled in the field.
Curb must be square and level.
Curb requires intermediate structural support and is not to be corner post mounted.
Gaskets to be shipped with unit.
Bolting accessories shipped with curb.urb drawings shown are for units which have controls on the
"standard" side.
Figure 13. DFOA Roof Curb Models 215-230
Table 4. DFOA Roof Curb Models 215-230
Model Dimensions (feet/inches))
ABCDE F GHJ K
215 1’ - 4 "9 5/8 "1’ -
6 15/
16
"5 1/8 "1’ - 10
1/2
"1’ - 11 3/8 "6’ - 3 "5’ -
11 1/2
"7’ - 8 "7’ - 4 1/2"
218 1’ - 7 "9 5/8 "1’ -
10 1/
16
"5 1/8 "1’ - 4 "1’ - 11 3/8 "6’ - 3 "5’ -
11 1/2
"7’ - 8 "7’ - 4 1/2"
220 2’ - 0
7/8
"10 7/16 "2’ -
1 1/
16
"9 5/8 "2’ - 5
1/2
"2’ - 11 1/2 "7’ -
10
"7’ - 6
1/2
"10’ -
8
"10’ - 4 1/2"
222 2’ - 3
3/8
"10 7/16 "2’ -
3 9/
16
"9 5/8 "2’ - 0
5/8
"2’ - 11 1/2 "7’ -
10
"7’ - 6
1/2
"10’ -
8
"10’ - 4 1/2"
225 2’ - 7
3/8
"1’ - 2 13/
16
"2’ -
7 1/2
"1’ - 0
5/8
"3’ - 1
5/8
"2’ - 11 1/2 "7’ -
10
"7’ - 6
1/2
"12’ -
8
"12’ - 4 1/2"
230 3’ - 0
7/8
"1’ - 2 13/
16
"3’ -
1
"1’ - 0
5/8
"2’ - 2
5/8
"2’ - 11 1/2 "7’ -
10
"7’ - 6
1/2
"12’ -
8
"12’ - 4 1/2"
