10
RT-SVX057F-EN
Figure 2. Cooling with optional electrical heat overview (electric/electric)
DISCONNECT SWITCH ACCESS
CONDENSATE DRAIN CONNECTION
Figure 3. Cooling with optional electrical heat front and side views (electric/electric)
NOTES:
1. THROUGH THE BASE ELECTRICAL IS NOT STANDARD ON ALL UNITS.
2. VERIFY WEIGHT, CONNECTION, AND ALL DIMENSIONS WITH INSTALLER DOCUMENTS BEFORE INSTALLATION.
42.004”
42.558”
76.814”
20.735”
15.860”
7.860”
47.934”
44.675”
43.675”
42.175”
DDiimmeennssiioonnaall DDaattaa
