Operating Pressures
Table OP-1: Cooling mode operating pressures
Unit Size Entering
Load
(Degree F)
Entering Source Temperature (Degree F)
50 86 104
Suction
Pressure
Discharge
Pressure
Suction
Pressure
Discharge
Pressure
Suction
Pressure
Discharge
Pressure
EXWA 240 53.6 46-56 103-143 49-59 188-228 49-59 238-278
EXWA 240 86 61-71 111-151 84-94 205-245 87-97 259-299
Table OP-2: Heating mode operating pressures
Unit Size Entering
Load
(Degree F)
Entering Source Temperature (Degree F)
50 68 104
Suction
Pressure
Discharge
Pressure
Suction
Pressure
Discharge
Pressure
Suction
Pressure
Discharge
Pressure
EXWA 240 75 46-56 160-200 65-75 170-210 86-96 183-223
EXWA 240 104 49-59 245-285 68-78 254-294 94-107 268-308
EXWA 240 122 49-59 310-350 68-78 320-360 95-105 333-373
