RT-SVX51H-EN
15
Figure 10. Cooling with optional electric heat — manual damper
NOTE:
VERIFY WEIGHT, CONNECTION, AND ALL DIMENSION WITH INSTALLER DOCUMENTS BEFORE INSTALLATION.
BACK VIEW OF UNIT
LEFT VIEW OF UNIT
FAN
MANUAL DAMPER
HOOD
123 1/8”
18 1/4”
26 7/8”
24 7/8”
12 13/16”
86 15/16”
DDiimmeennssiioonnaall DDaattaa
