Alarms and Troubleshooting
OAU-SVX007A-EN 105
The variable speed compressor drive parameter locations
consist of a two-digit number (menu location) and a three-digit
number (parameter location) that are setup from the factory
based on the unit nameplate and values from Table 21 and
Table 22 for ZPV066 compressors.
Table 21. Variable speed compressor drive
programming based on cabinet size
Unit RPM
Pr 07.012
-124
B060, B072, G120, G144, D060, D072 3600 0.5
B084 3900 0.542
G180, D180 4400 0.611
B096 4500 0.625
G210 4700 0.653
B108 4900 0.681
G240 5400 0.75
Table 22. Parameters reference for ZPV066
compressors/-124 VS drive only
Parameter Description Value
00.077 User Security Status All menus (1)
07.011 Al2 Control Volt
07.012 Scaling (see table) -
07.014 Destination Address 29.017
07.015 A13 Control Thermo-No Trip
07.016 Scaling 1
07.018 Destination Address 29.045
00.006 Configuration control parameter
00 0010
0000 1000
00.032 Soft-start speed 1800 rpm
00.033 Soft start acceleration 3s
00.035 Normal running acceleration 10s
00.036 Normal running deceleration 10s
00.037 Shutdown deceleration 10s
00.038 Shutdown hold speed 1000 rpm
00.039 Controlled shutdown dwell time 15s
00.040 Stop deceleration 10s
00.041 Oil boost threshold speed 1800 rpm
00.042 Oil boost threshold time 120 min
00.043 Oil boost acceleration rate 10s
00.044 Oil boost deceleration rate 10s
10.030 N/A 0
10.031 N/A 0
10.061 N/A 0
