mild bleach and water solution or an EPA-approved

sanitizer specifically designed for HVAC use.

Carefully follow the sanitizer manufacturer’s

instructions regarding product use.

6. Immediately rinse the drain pan thoroughly with

fresh water to prevent potential corrosion from the

cleaning solution.

7. Allow the unit to dry thoroughly before putting the

system back into service.

8. Properly dispose of all contaminated materials and

cleaning solution.

Inspecting and Cleaning the Fan

WWAARRNNIINNGG

HHaazzaarrddoouuss VVoollttaaggee ww//CCaappaacciittoorrss!!

FFaaiilluurree ttoo ddiissccoonnnneecctt ppoowweerr aanndd ddiisscchhaarrggee

ccaappaacciittoorrss bbeeffoorree sseerrvviicciinngg ccoouulldd rreessuulltt iinn ddeeaatthh oorr

sseerriioouuss iinnjjuurryy..

DDiissccoonnnneecctt aallll eelleeccttrriicc ppoowweerr,, iinncclluuddiinngg rreemmoottee

ddiissccoonnnneeccttss aanndd ddiisscchhaarrggee aallll mmoottoorr ssttaarrtt//rruunn

ccaappaacciittoorrss bbeeffoorree sseerrvviicciinngg.. FFoollllooww pprrooppeerr

lloocckkoouutt//ttaaggoouutt pprroocceedduurreess ttoo eennssuurree tthhee ppoowweerr

ccaannnnoott bbee iinnaaddvveerrtteennttllyy eenneerrggiizzeedd.. FFoorr vvaarriiaabbllee

ffrreeqquueennccyy ddrriivveess oorr ootthheerr eenneerrggyy ssttoorriinngg

ccoommppoonneennttss pprroovviiddeedd bbyy TTrraannee oorr ootthheerrss,, rreeffeerr ttoo

tthhee aapppprroopprriiaattee mmaannuuffaaccttuurreerr’’ss lliitteerraattuurree ffoorr

aalllloowwaabbllee wwaaiittiinngg ppeerriiooddss ffoorr ddiisscchhaarrggee ooff

ccaappaacciittoorrss.. VVeerriiffyy wwiitthh aa CCAATT IIIIII oorr IIVV vvoollttmmeetteerr

rraatteedd ppeerr NNFFPPAA 7700EE tthhaatt aallll ccaappaacciittoorrss hhaavvee

ddiisscchhaarrggeedd..

FFoorr aaddddiittiioonnaall iinnffoorrmmaattiioonn rreeggaarrddiinngg tthhee ssaaffee

ddiisscchhaarrggee ooff ccaappaacciittoorrss,, sseeee PPRROODD--SSVVBB0066**--EENN..

Inspect the fan section every six months or more

frequently if operating experience dictates. Clean

accumulated dirt and organic matter on the fan interior

surfaces using the following procedure:

1. Disconnect all electrical power to the unit.

2. Wear the appropriate personal protective

equipment (PPE).

3. Use a portable vacuum with HEPA filtration to

remove the loose dirt and organic matter. The filter

should be 99.97% efficient at 0.3 micron particle

size.

4. Thoroughly clean the fan and associated

components with an industrial cleaning solution.

Carefully follow the cleaning solution

manufacturer’s instructions regarding personal

protection and ventilation when using their

product.

5. Rinse the affected surfaces thoroughly with fresh

water and a fresh sponge to prevent potential

corrosion of metal surfaces.

6. Allow the unit to dry completely before putting it

back into service.

7. Properly dispose of all contaminated materials and

cleaning solution.

Supply Fan

IImmppoorrttaanntt:: On units ordered with a Design Special of

Inlet Guide Vanes, refer to non-current IOM

(SCXF-SVX01D-EN) dated on or before

March 2008 for maintenance procedure.

Fan Drive
