50
L8V1-SVX001-1A-EN
Table 18. Pressure Transducer
E18 Source Voltage 5Vdc Pins 1-2 (GR-RD)
Hot Header Pressure Inches W.C.
Transducer Signal Vdc Pins 1-3 (GR-BK @ E18)
0.00 0.50
0.10 0.60
0.20 0.70
0.30 0.80
0.40 0.90
0.50 1.00
0.60 1.10
0.70 1.20
0.80 1.30
0.90 1.40
1.00 1.50
1.10 1.60
1.20 1.70
1.30 1.80
1.40 1.90
1.50 2.00
1.60 2.10
1.70 2.20
1.80 2.30
1.90 2.40
2.00 2.50
2.10 2.60
2.20 2.70
2.30 2.80
2.40 2.90
2.50 3.00
2.60 3.10
2.70 3.20
2.80 3.30
2.90 3.40
3.00 3.50
3.10 3.60
3.20 3.70
3.30 3.80
3.40 3.90
3.50 4.00
3.60 4.10
3.70 4.20
3.80 4.30
3.90 4.40
4.00 4.50
LLEEDD FFaauulltt CCooddeess
