ACYSTAT-IOM-EN
23
Locating the Freeze Sensor
Installation
Locating the Temperature Sensor
Locate the return air sensor directly in the air returning to
the fan coil or air handler. It should be located so as not to
interfere with inspection or removal of return air filters or
servicing and repair fan coil or air handler.
Locate the freeze sensor
Locate the freeze sensor close to either U bend tube.
