12 LPC-SVX01C-EN
Installation
general
information
Digit 23 - Motor horsepower (hp)
0 = none
A =
1
/
2
hp
B =
3
/
4
hp
C = 1 hp
D = 1
1
/
2
hp
E = 2 hp
F = 3 hp
G = 5 hp
H = 7
1
/
2
hp
J = 10 hp
K = 15 hp
L = 20 hp
Digit 24 - Volume control
A = CV with variable pitch sheaves
B = CV with fixed pitch sheaves
C = VFD with fixed pitch sheaves
Digit 25 – Drives, fixed/variable
0 = none
A = 650 rpm/600 – 700 rpm
B = 700 rpm/650 – 750 rpm
C = 750 rpm/700 – 800 rpm
D = 800 rpm/750 – 850 rpm
E = 850 rpm/800 – 900 rpm
F = 900 rpm/850 – 950 rpm
G = 950 rpm/900 – 1000 rpm
H = 1000 rpm/950 – 1050 rpm
J = 1050 rpm/1000 – 1100 rpm
K = 1100 rpm/1050 – 1150 rpm
L = 1150 rpm/1100 – 1200 rpm
M = 1200 rpm/1150 – 1250 rpm
N = 1250 rpm/ 1200 – 1300 rpm
P = 1300 rpm/1250 – 1350 rpm
R = 1350 rpm/1300 – 1400 rpm
T = 1400 rpm/1350 – 1450 rpm
U = 1450 rpm/1400 – 1500 rpm
V = 1500 rpm/1450 – 1550 rpm
W = 1550 rpm/1500 – 1600 rpm
Y = 1600 rpm/1550 – 1650 rpm
Z = 1650 rpm/1600 – 1700 rpm
1 = 1700 rpm/1650 – 1750 rpm
2 = 1750 rpm/1700 – 1800 rpm
3 = 1800 rpm/1750 – 1850 rpm
4 = 1850 rpm/1800 – 1900 rpm
5 = 1900 rpm/1850 – 1950 rpm
6 = 1950 rpm/1900 – 2000 rpm
7 = 2000 rpm/1950 – 2050 rpm
Digit 26 - Filter type/filter/mixing section
0 = none
A = flat unit filter
B = flat unit filter & mixing section
C = angle filter section
D = flat filter section
E = angle filter section & mixing section
F = flat filter section & mixing section
Digit 27 – Face & bypass section (F & B,
preheat position)
0 = none
A = F & B w/ NC actuator
B = F & B w/ NO actuator
C = F & B w/ field-supplied NO actuator
D = F & B w/ field-supplied NC actuator
Digit 28 - Control option
0 = none
1 = dehumidification w/RH sensor
2 = dehumidification w/comm.RH
3 = 2-pipe changeover w/EWT sensor
4 = 2-pipe changeover w/comm. EWT
5 = CO
2
sensor
6 = 1 & 4
Digit 29 - Control options 1, factory
mounted
0 = none
A = low limit switch
B = condensate overflow switch
C = dirty filter switch
D = fan status switch
combined options
E = A and B
F = A and C
G = A and D
H = B and C
J = B and D
K = C and D
L = A, B, and, C
M = A, B, and D
N = A, C, and D
P = B, C, and D
R = A, B, C, and D
Digit 30 - Control options 2
0 = none
A = discharge air sensor (DAS)
B = mixed air sensor (MAS)
D = NO mixing box act.
E = NC mixing box act.
combined options
F = A and B
H = A and D
J = A and E
L = B and D
M = B and E
R = A, B, and D
T = A, B, and E
1 = field mounted, NO, mixing box act.
2 = field mounted, NC, mixing box act.
3 = DAS & field sup. NO mixing box act.
4 = DAS & field sup. NC, mixing box act.
5 = MAS & field sup. NO mixing box act.
6 = MAS & field sup. NC mixing box act.
7 = DAS, MAS field sup. NO mix. box act.
8 = DAS, MAS field sup. NC mix. box act.
Digit 31 - Control function
0 = none
1 = mixed air ctrl.
2 = mixed air preheat ctrl.
3 = economizing with mixed air ctrl.
4 = economizing with mixed air preheat ctrl.
Digit 32 - Control options 3, factory
provided, field installed
0 = none
A = outdoor air temperature sensor
B = duct static pressure sensor
C = A & B
D = outdoor air temperature communicated
E = duct static pressure communicated
F = D & E
Digit 33 – Preheat control valve options
0 = none
A =
3
/
4
” 2-way, NO 7.3 Cv
B =
3
/
4
” 2-way, NC 7.3 Cv
C =
3
/
4
” 3-way, NO 7.3 Cv
D =
3
/
4
” 3-way, NC 7.3 Cv
E = 1” 2-way, NO 11.6 Cv
F = 1” 2-way, NC 11.6 Cv
G = 1” 3-way, NO 11.6 Cv
H = 1” 3-way, NC 11.6 Cv
J = 1
1
/
4
” 2-way, NO 18.5 Cv
K = 1
1
/
4
” 2-way, NC 18.5 Cv
L = 1
1
/
4
” 3-way, NO 18.5 Cv
M = 1
1
/
4
” 3-way, NC 18.5 Cv
N = 1
1
/
2
” 2-way, NO 28.9 Cv
P =1
1
/
2
” 2-way, NC 28.9 Cv
Q = 1
1
/
2
” 3-way, NO 28.9 Cv
R =1
1
/
2
” 3-way, NC 28.9 Cv
T = 2” 2-way, NO 46.2 Cv
U = 2” 2-way, NC 46.2 Cv
V = 2” 3-way, NO 46.2 Cv
W = 2” 3-way, NC 46.2 Cv
X = 2
1
/
2
” 2-way, NO 54 Cv
Y = 2
1
/
2
” 2-way, NC 54 Cv
Z = 2
1
/
2
” 3-way, NO 54 Cv
1 = 2
1
/
2
” 3-way, NC 54 Cv
2 = field supplied 2-way NO
3 = field supplied 2-way NC
6 = field supplied 3-way NO
7 = field supplied 3-way NC
Note: NO = Normally open & NC = Normally closed in the
valve’s de-energized state
