36 LPC-SVX01C-EN
electrical
requirements
Installation
Table ER-2. LPC Electric Heat kW Limits, Min./Max
unit size
voltage 3 6 8 10 12 14 17 21 25 30
208/60/1 6/9 6/18 7/18 8/28 N/A N/A N/A N/A N/A N/A
230/60/1 6/11 6/20 7/20 8/30 N/A N/A N/A N/A N/A N/A
277/60/1 6/13 6/24 7/24 8/38 N/A N/A N/A N/A N/A N/A
208/60/3 6/13 6/26 7/28 8/41 10/50 12/50 14/50 17/50 20/47 20/41
230/60/3 6/13 6/26 7/32 8/41 10/53 12/59 14/59 17/59 20/56 20/50
460/60/3 6/13 6/24 7/32 8/44 10/53 12/63 14/75 17/95 20/95 20/120
575/60/3 6/13 6/26 7/34 8/44 10/53 12/63 14/75 17/95 20/95 20/120
380/50/3 6/13 6/26 7/32 8/44 10/53 12/63 14/75 17/95 20/95 20/95
415/50/3 6/13 6/26 7/32 8/44 10/53 12/63 14/75 17/95 20/95 20/95
minimum air flow
cfm 1050 2100 2800 3500 4200 4900 5950 7350 8750 10,500
Note:
1. Heaters available in the following kW
increments:
614 26 4471110
715 28 4775115
8 16 30 50 79 120
917 32 5383
10 18 34 56 87
11 20 36 59 91
12 22 38 63 95
13 24 41 67 100
1. Units drawing less than 100 amps are available with or without door interlocking disconnect.
Units drawing more than 100 amps are not available with door interlocking disconnect.
2. Units drawing less than 48 amps are available with or without line fusing.
Units drawing greater than 48 amps have line fusing as standard.
3. Units with electric heat must not be run below the minimum cfm listed above.
Table ER-1. Electric heat voltage
unit heater
voltage voltage
208 208
230 240
277 277
460 480
575 600
380 380
415 415
Useful Formulas:
Single Phase Heater Amps = (kW x 1000)/ Voltage
Three Phase Heater Amps = (kW x 1000)/ (Voltage x 1.73)
Minimum Circuit Ampacity = MCA
MCA = 1.25 x (heater amps + motor FLA)
Maximum Fuse Size or Maximum Overcurrent Protection = MFS
MFS = (2.25 x motor FLA) + heater amps
kW = (Air Flow x Delta T) / K
Delta T = (kW x K) / Air Flow
K = 3145 (English)
K = 824.7 (SI)
HACR (Heating, Air-Conditioning and
Refrigeration) type circuit breakers are
required in the branch circuit wiring for all
fan-coils with electric heat.
SeeTables ED- 3 through ED-6 for motor
FLAs
Select a standard fuse size or HACR type
circuit breaker equal to the MCA.
Use the next larger standard size if the
MCA does not equal a standard size.
Standard fuse sizes are:
15, 20, 25, 30, 35, 40, 45, 50, 60 amps
