LPC-SVX01C-EN 37
electrical
requirements
Installation
Table ER-3. Motor electrical characteristics & motor/VFD weight, lbs.
utilization motor motor VFD VFD
hp voltage FLA LRA RPM weight frame size line input weight
0.5 208/60/1 3.7 17.4 1725 23 56
230/60/1 3.6 17.3
277/60/1 3.2 14.5 1725 23 56
208/60/3 2.1 15 1725 21 56
230/60/3 2.2 13 1725 23 56
460/60/3 1.1 6.5
0.75 208/60/1 5 28.9 1725 33 56
230/60/1 4.9 29
277/60/1 4.2 29 1725 33 56
208/60/3 3.1 20.5 1725 24 56
230/60/3 3 20 1725 27 56
460/60/3 1.5 10
1 208/60/1 5.3 32.9 1725 35 56
230/60/1 5 33
277/60/1 4.1 30 1725 35 56
208/60/3 3.1 20.3 1725 33 56 6.3 27
230/60/3 2.8 20 6.3 27
460/60/3 1.4 10 2.5 27
575/60/3 1.1 8 1725 34 56 2.3 31
400/50/3 2.1 16.8 1450 39 56 2.8 27
1.5 208/60/3 5 34.4 1740 6.3 27
230/60/3 4.6 34 6.3 27
460/60/3 2.3 17 2.5 27
575/60/3 1.65 12.6 1740 39 56 2.3 31
400/50/3 2.5 19.7 1450 40 56 2.8 27
2 208/60/3 5.9 42.3 7.3 27
230/60/3 5.6 42 1725 7.3 27
460/60/3 2.8 21 3.4 27
575/60/3 2.2 16.8 1740 45 56 2.6 31
400/50/3 3.6 31.6 1450 56 56 3.8 27
3 208/60/3 8.7 64.7 10.4 31
230/60/3 8 64 1725 10.4 31
460/60/3 4 32 4.8 27
575/60/3 3.2 25.6 1725 56 56 3.8 31
400/50/3 5.5 44.6 1450 74 182-4T 5.3 27
5 208/60/3 14 91.8 16.8 31
230/60/3 13.2 91 1740 16.8 31
460/60/3 6.6 45.5 8.3 31
575/60/3 5.3 36.4 1740 74 182-4T 5.9 31
400/50/3 9.5 68.1 1450 113 213-5T 9.1 31
7.5 208/60/3 22.2 139.4 23.8 76
230/60/3 21.6 138.8 1760 23.8 76
460/60/3 10.8 69.4 10.6 31
575/60/3 8 49 1760 113 213-5T 9.2 31
400/50/3 13.5 89.5 1450 129 213-5T 15.2 31
10 208/60/3 28 180 32.2 76
230/60/3 28 180 1760 32.2 76
460/60/3 14 90 14.2 31
575/60/3 11 72 1760 131 213-5T 11.1 31
400/50/3 18.5 148.7 1450 167 254T 24.0 76
15 208/60/3 40.6 301 48.3 84
230/60/3 40.6 301 1760 48.3 84
460/60/3 20.3 150.5 21.0 76
575/60/3 16.2 120 1760 162 254T 16.6 76
400/50/3 23 148 1465 235 254-6T 24.0 76
20 208/60/3 61 298 1760 198 254-6T 61.9 84
230/60/3 50 300 1760 235 254-6T 61.9 84
460/60/3 25 150 27.6 76
575/60/3 20 135 1760 242 254-6T 21.4 76
