LPC-SVX01C-EN 41
installation
procedure
Installation
Step 3.
Line up the holes on the unit and module
and attach together using a #10 - 16 x 0.5
inch screw.
Step 4.
Line up the corner brackets on the
module being joined.
Step 5.
Attach the corner brackets using a bolt
and nut.
Note: Gasketing is not required on these
units. The Packaged Climate Changer is
designed and tested to be used without
gasketing. All screws, nuts, and bolts
required for installation are field supplied.
