8 LPC-SVX01C-EN
Installation
general
information
Table I-GI-1. Packaged Climate Changer General Data
Unit size 3 6 8 10 12 14 17 21 25 30
Unit nominal airflow, cfm 1500 3000 4000 5000 6000 7000 8500 10500 12500 15000
Hydronic & DX coil
coil area, ft
2
2.8 5.6 7.5 9.7 12.4 14.3 16.9 20.6 24.2 28.8
width, in. 17.5 22.5 27.5 27.5 35.0 35.0 45.0 45.0 51.2 51.2
length, in. 23.0 36.0 39.0 51.0 51.0 59.0 54.0 66.0 68.0 81.0
velocity, ft./min. 536.7 533.3 537.1 513.3 484.0 488.1 503.7 509.1 516.5 520.3
dry weight, lbs.
Note
10
1-row 23.5 35.0 41.8 51.5 66.2 72.1 82.8 93.2 109.7 122.5
2-row 29.5 46.3 56.8 70.8 91.0 100.5 116.6 134.2 168.5 190.2
4-row 46.6 75.8 94.7 120.5 152.8 170.7 207.3 240.7 276.3 317.0
6-row 58.6 98.5 124.7 159.3 202.4 227.8 274.9 322.8 372.7 431.2
8-row 73.6 125.4 159.5 204.7 259.4 292.9 351.3 414.5 479.5 556.8
wet weight, lbs.
Note
10
1-row 29.2 43.6 52.5 64.0 85.8 93.2 108.2 121.5 141.9 158.2
2-row 37.7 59.0 73.0 90.5 119.9 132.4 161.1 184.4 226.6 255.4
4-row 59.8 97.6 123.1 155.7 201.6 225.4 279.1 323.9 373.1 427.8
6-row 76.9 129.4 165.2 210.0 271.2 305.3 374.0 438.9 508.2 587.7
8-row 96.9 165.5 212.2 271.0 348.2 393.3 477.6 563.5 653.7 759.0
waterflow limits
1-row
min. gpm
Note
3
6.1 7.9 9.6 9.6 12.2 12.2 15.7 15.7 17.5 17.5
max. gpm
Note
4
32.6 42.0 51.3 51.3 65.3 65.3 83.9 83.9 93.3 93.6
2, 4, 6, & 8-row
min. gpm
Note
3
6.1 14.9 18.4 18.4 23.6 23.6 30.6 30.6 35.0 35.0
max. gpm
Note
4
32.6 79.3 51.3 51.3 65.3 125.9 163.2 163.2 186.6 186.6
volume, gallons
1-row 0.7 1.0 1.3 1.5 2.3 2.5 3.1 3.4 3.9 4.3
2-row 1.0 1.5 2.0 2.4 3.5 3.8 5.3 6.0 7.0 7.8
4-row 1.6 2.6 3.4 4.2 5.9 6.6 8.6 10.0 11.6 13.3
6-row 2.2 3.7 4.9 6.1 8.3 9.3 11.9 13.9 16.3 18.8
8-row 2.8 4.8 6.3 7.9 10.6 12.0 15.2 17.9 20.9 24.3
Steam coil
area, ft
2
1.9 4.5 6.5 8.5 11.7 13.5 6.8 8.4 11.0 13.2
width, in.
Note 5
12.0 18.0 24.0 24.0 33.0 33.0 18.0 18.0 24.0 24.0
length, in.
Note 6
23.0 36.0 39.0 51.0 51.0 59.0 54.0 67.0 66.0 79.0
area, ft
2
Note 7
– – – – – – 9.0 11.2 11.0 13.2
width, in.
Notes 5 & 7
– – – – – – 24.0 24.0 24.0 24.0
length, in.
Notes 6 & 7
– – – – – – 54.0 67.0 66.0 79.0
weight, lbs. 31.7 54.8 74.8 86.0 114.1 123.3 157.6 179.9 200.0 224.2
Fan/motor data
fan wheel size, in. 9x7 12x9 12x12 15x15 18x15 18x18 20x15 20x20 20x18 22x20
max rpm 2000 1500 1700 1400 1200 1200 1100 1000 1300 1150
motor HP
1
/
2
- 2
1
/
2
- 3
3
/
4
- 5 1 - 5 1 - 7
1
/
2
1 - 7
1
/
2
1 -10 2 - 15 3 - 20 3 - 20
min. design cfm
Note
8
1050 2100 2800 3500 4200 4900 5950 7350 8750 10500
max. design cfm
Note 9
1800 3600 4800 6000 7200 8400 10200 12600 15000 18000
2 and 4-in. Flat filter data
quantity - size in. 1 - 20x25 2 - 20x25 2 - 20x25 1 - 16x25 2 - 16x20 2 - 16x20 2 - 16x20 2 - 16x20 2 - 16x25 6 - 16x25
2 - 20x25 1 - 16x25 1 - 16x25 2 - 16x25 2 - 16x25 6 - 20x25 4 - 20x25
2 - 20x20 2 - 20x20 2 - 20x20 2 - 20x20
1 - 20x25 1 - 20x25 2 - 20x25 2 - 20x25
area, ft
2
3.5 6.9 6.9 9.7 16.3 16.3 22.5 22.5 26.4 30.6
nominal air velocity, ft./min. 432.0 432.0 576.0 514.3 369.2 430.8 377.8 466.7 473.5 490.2
2-in. Angle filter section data
quantity - size in. 2 - 16x25 4 - 20x20 4 - 20x20 4 - 20x20 9 - 20x20 9 - 20x20 6 - 16x25 6 - 16x25 4 - 16x20 12 - 16x20
2 - 16x20 6 - 20x25 6 - 20x25 12 - 20x20 8 - 20x20
area, ft
2
5.6 11.1 11.1 15.6 25.0 25.0 37.5 37.5 42.2 48.9
velocity, ft./min. 270.0 270.0 360.0 321.3 240.0 280.0 226.7 280.0 296.2 306.7
Mixing section
nominal air velocity, ft./min. 966.4 1066.3 1123.4 1120.4 1184.1 1161.7 1171.1 1120.1 1218.5 1247.1
Notes:
1. Coil width = length in the direction of a coil header, typically vertical.
2. Coil length = length of coil in direction of the coil tubes, typically horizontal and perpendicular to airflow.
3. Unit sizes 17-30 have two stacked steam coils. 4. To prevent erosion/noise problems. 5.
Coil width = length in the direction of a coil header, typically vertical. 6
. Coil length = length of
coil in direction of the coil tubes, typically horizontal and perpendicular to airflow. 7.
The minimum waterflow is to assure self venting of the coil. There is no minimum water flow limit
for coils that do not require self venting. 8.
Minimum airflow limit is for units with hot water, steam, or electric heat. There is no minimum airflow for cooling only units. 9. Due to
moisture carryover limits. 10. Coil weight based on 12 fpi coil.
