Trane Mini User Manual

24
Mini / Multi-Split Programmable Controller
Fig. 20 Lock Setting
4 Installation Instructions
4.1 Parts and Dimensions of Wired Controller
Fig. 21 Dimensions of wired controller
Fig. 22 Parts of wired controller
No. 1 2 3
Name
Panel of wired
controller
Screw M4 × 25
Mounting plate of
wired controller
Quantity 1 3 1
31 2
unit：mm

Trane Mini Specifications

General

Compatibility	Trane HVAC Systems
Display	Touchscreen
Functions	Scheduling
Battery Type	Lithium
Operating Range	32°F to 122°F (0°C to 50°C)
