[ III Specifications ]
- 5 -
HWE1832A GB
III Specifications
[1] Specifications
1. Specifications
Model TPEFYP006MA143A TPEFYP008MA143A TPEFYP012MA143A TPEFYP015MA143A
Power source 1-phase 208/230V 60Hz
Cooling capacity *1 BTU / h 6,000 8,000 12,000 15,000
(Nominal) *1 kW 1.8 2.3 3.5 4.4
Power input kW 0.06 0.06 0.09 0.09
Current input A 0.56/0.52 0.56/0.52 0.66/0.62 0.67/0.63
Heating capacity *2 BTU / h 6,700 9,000 13,500 17,000
(Nominal) *2 kW 2.0 2.6 4.0 5.0
Power input kW 0.04 0.04 0.07 0.07
Current input A 0.45/0.41 0.45/0.41 0.55/0.51 0.56/0.52
External finish Galvanized steel plate
External dimension H x W x D in. 9-7/8x27-9/16x28-7/8 9-7/8x27-9/16x28-7/8 9-7/8x27-9/16x28-7/8 9-7/8x35-7/16x28-7/8
mm 250 x 700 x 732 250 x 700 x 732 250 x 700 x 732 250 x 900 x 732
Net weight lbs (kg) 49(22) 49(22) 49(22) 58(26)
Heat exchanger Cross fin (Aluminium fin and copper tube)
FAN Type x Quantity Sirocco fan x 1 Sirocco fan x 1 Sirocco fan x 1 Sirocco fan x 1
External in.WG <0.14>-0.20-<0.28>-<0.40>-<0.60>
static press. Pa <35>-50-<70>-<100>-<150>
Motor type DC motor
Motor output kW 0.085 0.085 0.085 0.085
Driving mechanism Direct-driven by motor
Airflow rate cfm 212-265-300 212-265-300 265-318-371 353-424-494
(Low-Mid-High) m
3
/ min 6.0-7.5-8.5 6.0-7.5-8.5 7.5-9.0-10.5 10.0-12.0-14.0
L / s 100-125-142 100-125-142 125-150-175 167-200-233
Sound pressure level
dB <A> 26-28-29 26-28-29 28-30-34 28-30-34
(Low-Mid-High)
(measured in anechoic room)
Insulation material EPS, Polyethylene foam,Urethane foam
Air filter PP honeycomb fabric
Protection device Fuse
Refrigerant control device LEV
Connectable outdoor unit R410A CITY MULTI
Diameter of
Liquid (R410A) in. (mm) 1/4 (6.35) Brazed 1/4 (6.35) Brazed 1/4 (6.35) Brazed 1/4 (6.35) Brazed
refrigerant
pipe
Gas (R410A) in. (mm) 1/2 (12.7) Brazed 1/2 (12.7) Brazed 1/2 (12.7) Brazed 1/2 (12.7) Brazed
(O.D.)
Diameter of drain pipe in. (mm) O.D. 1-1/4(32)
Drawing External -
Wiring -
Refrigerant cycle -
Standard Document Installation Manual, Instruction Book
attachment Accessory Washer, Drain hose, Tie band
Optional External heater adapter PAC-YU25HT
parts Filter box PAC-KE91TB-E PAC-KE91TB-E PAC-KE91TB-E PAC-KE92TB-E
Remark Installation Details on foundation work, duct work, insulation work, electrical wiring, power source switch, and other
items shall be referred to the Installation Manual.
Due to continuing improvement, above specifications may be subject to change without notice.
Note : *1 Nominal cooling conditions *2 Nominal heating conditions Unit convertor
Indoor : 80degF D.B. / 67degF W.B. 70degF D.B. kcal/h = kW x 860
(26.7degC D.B. / 19.4degC W.B.) (21.1degC D.B.) BTU/h = kW x 3,412
Outdoor : 95degF D.B. 47degF D.B. / 43degF W.B. cfm = m
3
/min x 35.31
(35degC D.B.) (8.3degC D.B. / 6.1degC W.B.) lbs = kg / 0.4536
Pipe length : 25 ft. (7.6 m) 25 ft. (7.6 m)
Level difference : 0 ft. (0 m) 0 ft. (0 m) *Above specification data is
*The external static pressure is set to 0.20in. WG(50Pa) at factory shipment. subject to rounding variation.
*Due to continuing improvement, above specification may be subject to change without notice.
