Unit Installation
[Fix the hanger bracket] [Fix the washer]
[Fix the installation paperboard]
Insert
Washer guide plate
(accessory)
Nut (provided on-site)
Hanger bracket
Tighten (double nut)
Washer
(accessory)
Fix the screw at the corner of outlet pipe at
the drainage tank corner
Center of the
ceiling hatch
Installation paperboard
Screw (accessory)
Screw (accessory)
PE pipe
Level
Figure 5.
Warning
Please tighten the nuts and bolts, preventing the air conditioning falling.
