Trane NO Series User Manual

20
Airflow Data
Table 5. Nominal Heating Airflow Rates & Temperature Rises (° F)
MODEL
NUMBER
HEATING
RISE
RANGE
(BTU/H)
MOTOR
TAP
EXTERNAL STATIC PRESSURE DROP - INCHES WATER COLUMN
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
(ACFM)
(°F)
RISE
(ACFM)
(°F)
RISE
(ACFM)
(°F)
RISE
(ACFM)
(°F)
RISE
(ACFM)
(°F)
RISE
(ACFM)
(°F)
RISE
(ACFM)
(°F)
RISE
(ACFM)
(°F)
RISE
4YCL4024A1055A
35-65
Tap T1** 996 41 898 46 800 52 750 55 726 57 632 65 552 75 470 88
Tap T2
Tap T3
Tap T4
Tap T5
4YCL4030A1070A
35-65
Tap T1 1243 42 1158 45 1076 49 984 53 906 58 845 62 704 75 686 77
Tap T2 1319 40 1235 43 1166 45 1079 49 1003 52 934 56 782 67 718 73
Tap T3** 1393 38 1310 40 1255 42 1172 45 1099 48 1021 51 955 55 809 65
Tap T4
Tap T5
4YCL4036A1070A
35-65
Tap T1 1243 42 1158 45 1076 49 984 53 906 58 845 62 782 67 686 77
Tap T2** 1393 38 1310 40 1255 42 1172 45 1099 48 1021 51 860 61 809 65
Tap T3
Tap T4
Tap T5
4YCL4042A1100A
35-65
Tap T1 999 75 928 81 868 86 806 93 741 101 696 108 629 119 564 133
Tap T2 1390 54 1337 56 1290 58 1235 61 1173 64 1131 66 1083 69 1030 73
Tap T3** 1513 50 1461 51 1402 53 1355 55 1297 58 1243 60 1202 62 1147 65
Tap T4
Tap T5
4YCL4048A1100A
35-65
Tap T1 999 75 928 81 868 86 806 93 741 101 696 108 629 119 564 133
Tap T2 1390 54 1337 56 1299 58 1235 61 1173 64 1131 66 1083 69 1030 73
Tap T3** 1513 50 1461 51 1402 53 1355 55 1297 58 1243 60 1120 67 1147 65
Tap T4
Tap T5
4YCL4060A1100A
35-65
Tap T1 1589 47 1498 50 1391 54 1271 59 1165 64 1063 71 995 75 899 83
Tap T2** 1803 42 1710 44 1621 46 1513 50 1416 53 1320 57 1241 60 1146 65
Tap T3
Tap T4
Tap T5
** Denotes factory set heating speed
Tap 1 is fan only
(†) Part number may contain a C or X.
Data is shown without a filter
Heat rise: Btu/h (Input) = CFM * Δ T * 1.081
Δ T = (Btu/h * 0.83) / (CFM * 1.081)
To comply with government mandated efficiency standards, two openings are required for airflows above
1,600 CFM.
Temperature rises in the table are approximate. Actual temperature rises may vary.
Individual cells shaded in gray indicate a temperature rise outside the recommended range.
To comply with government mandated efficiency standards, speed settings which do not have data are not
allowed in HEAT mode.
Data is ACFM (Actual Cubic Feet per Minute)
