Trane Precedent WSJ150 User Manual

PKGP-SVX010A-EN
15
Figure 5. 12.5 to 25 tons standard efficiency – power exhaust
4.4
21.4
7.0
22.7
Figure 6. 12.5 to 25 tons standard efficiency – unit clearance and roof opening
UNIT OUTLINE
CLEARANCE 36”
914 MM
CLEARANCE 48”
1219 MM
FRONT OF UNIT
CLEARANCE 60”
1524 MM
CLEARANCE 68”
1727 MM
76 1/2”
1943 MM
81”
2057 MM
ROOF
OPENING
CLEARANCE FORM
TOP OF UNIT 72” MM (1829 MM)
Dimensional Data

Trane Precedent WSJ150 Specifications

General

Brand	Trane
Model	Precedent WSJ150
Category	Air Conditioner
Language	English
