Trane Precedent YHJ072 User Manual

RT-SVX075C-EN
17
Figure 10. 12.5 tons high efficiency
CONDENSER COIL
OUTDOOR TOP PANEL
INDOOR TOP PANEL
ALTERNATE CONDENSATE DRAIN
CONNECTION 3/4 - 14 NPT DIA HOLE
CONTROL BOX SECTION
ACCESS PANEL
UNIT POWER WIRE
1-3/8" (35MM) DIA. HOLE
1/2 NPT CONNECTION
(120 MBh)
3/4 NPT GAS CONNECTION
(150 MBh, 200 MBh, 250 MBh)
COMPRESSOR ACCESS PANEL
EVAPORATOR SECTION
ACCESS PANEL
UNIT POWER WIRE
1-3/8" (35MM) DIA. HOLE
UNIT POWER WIRE
2" (50MM) DIA. HOLE
SERVICE GAUGE PORT ACCESS
1-3/8" (35MM) DIA. HOLE
UNIT CONTROL WIRE
2" (50MM) DIA. HOLE
50-7/8"
[1293]
63-1/8"
[1604]
99-5/8"
[2532]
47-7/8"
[1217]
27-5/8"
[700]
Figure 11. 12.5 tons high efficiency – downflow airflow supply/return, through-the-base utilities
RETURN
SUPPLY
3 5/8”
92 MM
17 1/2”
444 MM
9 7/8”
251 MM
17 1/2”
444 MM
32 1/8”
816 MM
33”
838 MM
4”
102 MM
THROUGH THE
BASE ELECTRICAL
THROUGH THE
BASE CONDENSATE
4 5/8”
119 MM
THROUGH THE
BASE GAS
5 7/8”
149 MM
27 5/8”
701 MM
42 3/16”
1072 MM
6 3/8”
163 MM
2 3/4”
71 MM
51 3/16”
1316 MM
4 1/8”
104 MM
Dimensions and Weights
