20
RT-SVX075C-EN
Figure 16. 6 to 12.5 tons high efficiency – economizer, manual or motorized fresh air damper
DIMENSIONS EXTENDS TO 21-5/8" (549MM)
WHEN POWERED EXHAUST IS COUPLED
WITH LOW LEAK ECONOMIZER
ECONOMIZER HOOD
BAROMETRIC RELIEF HOOD
16-3/4"
[424]
7-1/4"
[185]
12"
[303]
7-3/4"
[198]
Dimensions and Weights
