Installation - Remote Condenser
.
Table 8 Liquid Line Sizes (O.D.) For Units with Leaving Evaporator Water Temp of 40-60 F with Daytime
40-60 F and Ice Making
35 Ton Circuit (40 - 60F LWT) 40 Ton Circuit (40 - 60F LWT)
To t a l
Equiv.
Length
(ft.)
Liquid Line Size (OD”)
To t a l
Equiv.
Length
(ft.)
Liquid Line Size (OD”)
Horizontal
or
Downflow
Upflow
1-5 ft.
Upflow
6-10 ft.
Upflow
11-15 ft.
Horizontal
or
Downflow
Upflow
1-5 ft.
Upflow
6-10 ft.
Upflow
11-15 ft.
25 1 1/8 1 1/8 1 1/8 1 1/8 25 1 1/8 1 1/8 1 1/8 1 1/8
50 1 1/8 1 1/8 1 1/8 1 1/8 50 1 1/8 1 1/8 1 1/8 1 3/8
75 1 1/8 1 1/8 1 1/8 1 3/8 75 1 1/8 1 1/8 1 1/8 1 3/8
100 1 1/8 1 1/8 1 1/8 1 3/8 100 1 1/8 1 1/8 1 1/8 1 3/8
125 1 1/8 1 1/8 1 1/8 1 3/8 125 1 1/8 1 1/8 1 3/8 1 3/8
150 1 1/8 1 1/8 1 1/8 1 3/8 150 1 1/8 1 1/8 1 3/8 1 3/8
175 1 1/8 1 1/8 1 3/8 1 3/8 175 1 1/8 1 3/8 1 3/8 1 5/8
200 1 1/8 1 1/8 1 3/8 1 3/8 200 1 1/8 1 3/8 1 3/8 1 5/8
225 1 1/8 1 1/8 1 3/8 1 5/8 225 1 3/8 1 3/8 1 3/8 1 5/8
250 1 1/8 1 3/8 1 3/8 1 5/8 250 1 3/8 1 3/8 1 3/8 1 5/8
275 1 1/8 1 3/8 1 3/8 1 5/8 275 1 3/8 1 3/8 1 3/8 1 5/8
300 1 3/8 1 3/8 1 3/8 1 5/8 300 1 3/8 1 3/8 1 3/8 1 5/8
50 Ton Circuit (40 - 60F LWT) 60 Ton Circuit (40 - 60F LWT)
To t a l
Equiv.
Length
(ft.)
Liquid Line Size (OD”)
To t a l
Equiv.
Length
(ft.)
Liquid Line Size (OD”)
Horizontal
or
Downflow
Upflow
1-5 ft.
Upflow
6-10 ft.
Upflow
11-15 ft.
Horizontal
or
Downflow
Upflow
1-5 ft.
Upflow
6-10 ft.
Upflow
11-15 ft.
25 1 1/8 1 1/8 1 1/8 1 1/8 25 1 1/8 1 1/8 1 1/8 1 3/8
50 1 1/8 1 1/8 1 1/8 1 3/8 50 1 1/8 1 1/8 1 3/8 1 3/8
75 1 1/8 1 1/8 1 3/8 1 3/8 75 1 1/8 1 1/8 1 3/8 1 5/8
100 1 1/8 1 1/8 1 3/8 1 3/8 100 1 1/8 1 3/8 1 3/8 1 5/8
125 1 1/8 1 3/8 1 3/8 1 5/8 125 1 3/8 1 3/8 1 3/8 1 5/8
150 1 1/8 1 3/8 1 3/8 1 5/8 150 1 3/8 1 3/8 1 3/8 1 5/8
175 1 3/8 1 3/8 1 3/8 1 5/8 175 1 3/8 1 3/8 1 5/8 1 5/8
200 1 3/8 1 3/8 1 3/8 1 5/8 200 1 3/8 1 3/8 1 5/8 2 1/8
225 1 3/8 1 3/8 1 5/8 1 5/8 225 1 3/8 1 3/8 1 5/8 2 1/8
250 1 3/8 1 3/8 1 5/8 2 1/8 250 1 3/8 1 5/8 1 5/8 2 1/8
275 1 3/8 1 3/8 1 5/8 2 1/8 275 1 3/8 1 5/8 1 5/8 2 1/8
300 1 3/8 1 3/8 1 5/8 2 1/8 300 1 3/8 1 5/8 1 5/8 2 1/8
