RLC-SVX07A-EN 51
Installation - Remote Condenser
Ta b l e 8 only applies to units that are designed for evaporator
leaving water temperatures between 20 - 39 F. A 2 or 4 must
appear in the 12th digit of the RTUA unit model number and the
unit must be designed to operate between 20 - 39 F before this
table can be used. If this table is used to size piping for standard
units. catastrophic damage to the unit may occur.
Table 9 Liquid Line Sizes (O.D.)
For Units with Leaving Evaporator Water Temp of 20-39 F
35 Ton Circuit (20 - 39F LWT) 40 Ton Circuit (20 - 39FLWT)
To t a l
Equiv.
Length
(ft.)
Liquid Line Size (OD”)
To t a l
Equiv.
Length
(ft.)
Liquid Line Size (OD”)
Horizontal
or
Downflow
Upflow
1-5 ft.
Upflow
6-10 ft.
Upflow
11-15 ft.
Horizontal
or
Downflow
Upflow
1-5 ft.
Upflow
6-10 ft.
Upflow
11-15 ft.
25 7/8 7/8 7/8 1 1/8 25 7/8 7/8 7/8 1 1/8
50 7/8 7/8 7/8 1 1/8 50 7/8 7/8 1 1/8 1 1/8
75 7/8 7/8 1 1/8 1 1/8 75 7/8 1 1/8 1 1/8 1 3/8
100 7/8 1 1/8 1 1/8 1 3/8 100 1 1/8 1 1/8 1 3/8 1 3/8
125 1 1/8 1 1/8 1 1/8 1 3/8 125 1 1/8 1 1/8 1 3/8 1 3/8
150 1 1/8 1 1/8 1 1/8 1 3/8 150 1 1/8 1 1/8 1 3/8 1 3/8
175 1 1/8 1 1/8 1 3/8 1 3/8 175 1 1/8 1 1/8 1 3/8 1 3/8
200 1 1/8 1 1/8 1 3/8 1 3/8 200 1 1/8 1 1/8 1 3/8 1 5/8
225 1 1/8 1 1/8 1 3/8 1 3/8 225 1 1/8 1 3/8 1 3/8 1 5/8
250 1 1/8 1 1/8 1 3/8 1 3/8 250 1 1/8 1 3/8 1 3/8 1 5/8
275 1 1/8 1 1/8 1 3/8 1 5/8 275 1 1/8 1 3/8 1 3/8 1 5/8
300 1 1/8 1 1/8 1 3/8 1 5/8 300 1 1/8 1 3/8 1 3/8 1 5/8
50 Ton Circuit (20 - 39F LWT) 60 Ton Circuit (20 - 39F LWT)
To t a l
Equiv.
Length
(ft.)
Liquid Line Size (OD”)
To t a l
Equiv.
Length
(ft.)
Liquid Line Size (OD”)
Horizontal
or
Downflow
Upflow
1-5 ft.
Upflow
6-10 ft.
Upflow
11-15 ft.
Horizontal
or
Downflow
Upflow
1-5 ft.
Upflow
6-10 ft.
Upflow
11-15 ft.
25 7/8 7/8 1 1/8 1 1/8 25 1 1/8 1 1/8 1 1/8 1 1/8
50 7/8 1 1/8 1 1/8 1 3/8 50 1 1/8 1 1/8 1 1/8 1 3/8
75 1 1/8 1 1/8 1 1/8 1 3/8 75 1 1/8 1 1/8 1 1/8 1 3/8
100 1 1/8 1 1/8 1 1/8 1 3/8 100 1 1/8 1 1/8 1 3/8 1 3/8
125 1 1/8 1 1/8 1 3/8 1 3/8 125 1 1/8 1 3/8 1 3/8 1 5/8
150 1 1/8 1 1/8 1 3/8 1 5/8 150 1 1/8 1 3/8 1 3/8 1 5/8
175 1 1/8 1 3/8 1 3/8 1 5/8 175 1 3/8 1 3/8 1 3/8 1 5/8
200 1 1/8 1 3/8 1 3/8 1 5/8 200 1 3/8 1 3/8 1 3/8 1 5/8
225 1 3/8 1 3/8 1 3/8 1 5/8 225 1 3/8 1 3/8 1 3/8 1 5/8
250 1 3/8 1 3/8 1 3/8 1 5/8 250 1 3/8 1 3/8 1 5/8 1 5/8
275 1 3/8 1 3/8 1 3/8 1 5/8 275 1 3/8 1 3/8 1 5/8 2 1/8
300 1 3/8 1 3/8 1 5/8 1 5/8 300 1 3/8 1 3/8 1 5/8 2 1/8
