Trane R Series User Manual

52 RLC-SVX07A-EN
Installation - Remote Condenser
Ta b l e 9 only applies to units that are designed for evaporator
leaving water temperatures between 0 - 19 F. A 2 or 4 must appear
in the 12th digit of the RTUA unit model number and the unit
must be designed to operate below 19 F before this table can be
used. If this table is used to size Dining for standard units.
catastrophic damage to the unit may occur.
Table 10 Liquid Line Sizes (O.D.)
For Units with Leaving Evaporator Water Temp of 0 -19 F
35 Ton Circuit (0 - 19 F LWT) 40 Ton Circuit (0 - 19 F LWT)
To t a l
Equiv.
Length
(ft.)
Liquid Line Size (OD”)
To t a l
Equiv.
Length
(ft.)
Liquid Line Size (OD”)
Horizontal
or
Downflow
Upflow
1-5 ft.
Upflow
6-10 ft.
Upflow
11-15 ft.
Horizontal
or
Downflow
Upflow
1-5 ft.
Upflow
6-10 ft.
Upflow
11-15 ft.
25 7/8 7/8 7/8 7/8 25 7/8 7/8 7/8 7/8
50 7/8 7/8 7/8 7/8 50 7/8 7/8 7/8 1 1/8
75 7/8 7/8 7/8 1 1/8 75 7/8 7/8 7/8 1 1/8
100 7/8 7/8 7/8 1 1/8 100 7/8 7/8 1 1/8 1 1/8
125 7/8 7/8 1 1/8 1 1/8 125 7/8 7/8 1 1/8 1 1/8
150 7/8 7/8 1 1/8 1 1/8 150 7/8 1 1/8 1 1/8 1 1/8
175 7/8 7/8 1 1/8 1 1/8 175 7/8 1 1/8 1 1/8 1 3/8
200 7/8 1 1/8 1 1/8 1 1/8 200 1 1/8 1 1/8 1 1/8 1 3/8
225 7/8 1 1/8 1 1/8 1 3/8 225 1 1/8 1 1/8 1 1/8 1 3/8
250 7/8 1 1/8 1 1/8 1 3/8 250 1 1/8 1 1/8 1 1/8 1 3/8
275 1 1/8 1 1/8 1 1/8 1 3/8 275 1 1/8 1 1/8 1 1/8 1 3/8
300 1 1/8 1 1/8 1 1/8 1 3/8 300 1 1/8 1 1/8 1 1/8 1 3/8
50 Ton Circuit (0 - 19 F LWT) 60 Ton Circuit (0 - 19 F LWT)
To t a l
Equiv.
Length
(ft.)
Liquid Line Size (OD”)
To t a l
Equiv.
Length
(ft.)
Liquid Line Size (OD”)
Horizontal
or
Downflow
Upflow
1-5 ft.
Upflow
6-10 ft.
Upflow
11-15 ft.
Horizontal
or
Downflow
Upflow
1-5 ft.
Upflow
6-10 ft.
Upflow
11-15 ft.
25 7/8 7/8 7/8 7/8 25 7/8 7/8 7/8 1 1/8
50 7/8 7/8 7/8 1 1/8 50 7/8 7/8 1 1/8 1 1/8
75 7/8 7/8 1 1/8 1 1/8 75 7/8 1 1/8 1 1/8 1 1/8
100 7/8 1 1/8 1 1/8 1 1/8 100 1 1 /8 1 1/8 1 1 /8 1 3/8
125 7/8 1 1/8 1 1/8 1 3/8 125 1 1 /8 1 1/8 1 1 /8 1 3/8
150 1 1/8 1 1/8 1 1/8 1 3/8 150 1 1/8 1 1/8 1 1/8 1 3/8
175 1 1/8 1 1/8 1 1/8 1 3/8 175 1 1/8 1 1/8 1 3/8 1 3/8
200 1 1/8 1 1/8 1 1/8 1 3/8 200 1 1/8 1 1/8 1 3/8 1 3/8
225 1 1/8 1 1/8 1 1/8 1 3/8 225 1 1/8 1 1/8 1 3/8 1 3/8
250 1 1/8 1 1/8 1 3/8 1 3/8 250 1 1/8 1 1/8 1 3/8 1 5/8
275 1 1/8 1 1/8 1 3/8 1 3/8 275 1 1/8 1 3/8 1 3/8 1 5/8
300 1 1/8 1 1/8 1 3/8 1 3/8 300 1 1/8 1 3/8 1 3/8 1 5/8
