Trane R Series User Manual

RLC-SVX07A-EN 53
Installation - Remote Condenser
Table 11 Maximum Allowable Liquid Line Drainable to the Evaporator
(Actual Ft.)
CIRCUIT SIZE Liquid
Line Size (O.D.) 30 Ton 40 Ton 50 Ton 60 Ton
1 1/8 200 200 200 200
1 3/8 125 125 175 200
Table 12 Horizontal or Downflow Discharge Line Sizes (O.D.)
35 Ton Circuit 40 Ton Circuit
To t a l
Equiv.
Length
(ft.)
Leaving Evaporator Water Temperature (F) To t a l
Equiv.
Length
(ft.)
Leaving Evaporator Water Temperature (F)
40 - 60 F 20 - 39 F 0 - 19 F 40 - 60 F 20 - 39 F 0 - 19 F
25 2 1/8 1 5/8 1 5/8 25 2 1/8 1 5/8 1 5/8
50 2 1/8 1 5/8 1 5/8 50 2 1/8 1 5/8 1 5/8
75 2 1/8 1 5/8 1 5/8 75 2 1/8 1 5/8 1 5/8
100 2 1/8 1 5/8 1 5/8 100 2 1/8 1 5/8 1 5/8
125 2 1/8 1 5/8 1 5/8 125 2 1/8 1 5/8 1 5/8
150 2 1/8 1 5/8 1 5/8 150 2 1/8 1 5/8 1 5/8
175 2 1/8 1 5/8 1 5/8 175 2 1 /8 1 5/8 1 5/8
200 2 1/8 1 5/8 1 5/8 200 2 1/8 1 5/8 1 5/8
225 2 1/8 2 1/8 1 5/8 225 2 1/8 2 1/8 1 5/8
250 2 1/8 2 1/8 1 5/8 250 2 1/8 2 1/8 1 5/8
275 2 1/8 2 1/8 1 5/8 275 2 1/8 2 1/8 1 5/8
300 2 1/8 2 1/8 1 5/8 300 2 1/8 2 1/8 1 5/8
50 Ton Circuit 60 Ton Circuit
To t a l
Equiv.
Length
(ft.)
Leaving Evaporator Water Temperature (F) To t a l
Equiv.
Length
(ft.)
Leaving Evaporator Water Temperature (F)
40 - 60 F 20 - 39 F 0 - 19 F 40 - 60 F 20 - 39 F 0 - 19 F
25 2 1/8 2 1/8 2 1/8 25 2 1/8 2 1/8 2 1/8
50 2 1/8 2 1/8 2 1/8 50 2 1/8 2 1/8 2 1/8
75 2 1/8 2 1/8 2 1/8 75 2 1/8 2 1/8 2 1/8
100 2 1/8 2 1/8 2 1/8 100 2 1/8 2 1/8 2 1/8
125 2 1/8 2 1/8 2 1/8 125 2 1/8 2 1/8 2 1/8
150 2 1/8 2 1/8 2 1/8 150 2 1/8 2 1/8 2 1/8
175 2 1/8 2 1/8 2 1/8 175 2 5/8 2 1/8 2 1/8
200 2 1/8 2 1/8 2 1/8 200 2 5/8 2 1/8 2 1/8
225 2 5/8 2 1/8 2 1/8 225 2 5/8 2 1/8 2 1/8
250 2 5/8 2 1/8 2 1/8 250 2 5/8 2 1/8 2 1/8
275 2 5/8 2 1/8 2 1/8 275 2 5/8 2 1/8 2 1/8
300 2 5/8 2 1/8 2 1/8 300 2 5/8 2 1/8 2 1/8
