RLC-SVX07A-EN 59
Installation - Electrical
Table 16 RTWA Electrical Data
Unit Wiring Motor Data
Unit Size
Rated Voltage
(V/HZ/Phase)
MCA (1)
Max. Fuse or
HACR (2)
Rec Time Delay
or RDE (3)
Qty.
Compressor (Ea)
RLA (4) LRA (6)
RTWA 70
Std. Cond. Temp
200/60/3 237 300 300 2 105/105 800/800
230/60/3 205 250 250 2 91/91 690/690
460/60/3 104 125 125 2 46/46 330/330
575/60/3 84 110 100 2 37/37 270/270
RTWA 80
Std. Cond. Temp
200/60/3 279 400 350 2 124/124 880/880
230/60/3 243 350 300 2 108/108 760/760
460/60/3 122 175 150 2 54/54 380/380
575/60/3 97 125 110 2 43/43 304/304
RTWA 90
Std. Cond. Temp
200/60/3 329 450 400 2 164/124 990/880
230/60/3 287 400 350 2 143/108 820/760
460/60/3 144 200 175 2 72/54 410/380
575/60/3 115 150 150 2 57/43 328/304
RTWA 100
Std. Cond. Temp
200/60/3 369 500 450 2 164/164 990/990
230/60/3 322 450 400 2 143/143 820/820
460/60/3 162 225 200 2 72/72 410/410
575/60/3 129 175 150 2 57/57 328/328
RTWA 110
Std. Cond. Temp
200/60/3 407 600 500 2 194/164 1190/990
230/60/3 355 500 400 2 169/143 1044/820
460/60/3 179 250 200 2 85/77 522/410
575/60/3 142 200 175 2 68/57 420/328
RTWA 125
Std. Cond. Temp
200/60/3 437 600 300 2 194/194 1190/1190
230/60/3 381 500 250 2 169/169 1044/1044
460/60/3 192 250 125 2 85/85 522/522
575/60/3 153 200 100 2 68/68 420/420
1. MCA-Minimum Circuit Ampacity - 125 percent of the largest compressor RLA plus 100 percent of the second compressor RLA.
2. HACR type circuit breaker for CSA only. Fuse size (HACR breaker) 225 percent of the largest compressor RLA plus 100 percent
of the second compressor RLA.
3. Recommended Time Delay or Dual Element (RDE) Fuse Size - 150 percent of the largest compressor RLA plus 100 percent of
the second compressor RLA.
4. Local codes may take precedence.
5. Voltage Utilization range:
6. RLA-Rated Load Amps - Rated in accordance with UL Standard 1995.
7. LRA-Locked Rotor Amps - Based on full winding starts.
8. Data containing information on two circuits shown as follows: ckt 1/ckt 2.
