Trane R Series User Manual

60 RLC-SVX07A-EN
Installation - Electrical
Table 17 RTUA and RTWA High Temp Condenser Electrical Data
Unit Wiring Motor Data
Unit Size
Rated Voltage
(V/HZ/Phase)
MCA (1)
Max. Fuse or
HACR (2)
Rec Time Delay
or RDE (3)
Qty.
Compressor (Ea)
RLA (4) LRA (6)
RTUA 70
RTWA 70 High
Cond.
Tem p
200/60/3 259 350 300 2 115/115 800/800
230/60/3 225 300 250 2 100/100 690/690
460/60/3 113 150 125 2 50/50 330/330
575/60/3 90 125 100 2 40/40 270/270
RTUA 80
RTWA 80 High
Cond.
Tem p
200/60/3 320 450 400 2 142/142 880/880
230/60/3 279 400 350 2 124/124 760/760
460/60/3 140 200 175 2 62/62 380/380
575/60/3 113 150 125 2 50/50 304/304
RTUA 90
RTWA 90 High
Cond.
Tem p
200/60/3 382 500 450 2 192/142 990/880
230/60/3 333 450 400 2 167/124 820/760
460/60/3 167 250 200 2 84/62 410/380
575/60/3 134 200 175 2 67/50 328/304
RTUA 100
RTWA 100 High
Cond.
Tem p
200/60/3 432 600 500 2 192/192 990/990
230/60/3 376 500 450 2 167/167 820/820
460/60/3 189 250 225 2 84/84 410/410
575/60/3 151 200 175 2 67/67 328/328
RTUA 110
RTWA 110 High
Cond.
Tem p
200/60/3 484 700 600 2 233/192 1190/990
230/60/3 421 600 600 2 203/167 1044/820
460/60/3 211 300 250 2 101/84 522/410
575/60/3 169 225 200 2 81/67 420/328
RTUA 125
RTWA 125 High
Cond.
Tem p
200/60/3 525 700 600 2 233/233 1190/1190
230/60/3 457 600 600 2 203/203 1044/820
460/60/3 228 300 250 2 101/101 522/522
575/60/3 183 250 225 2 81/81 420/420
1. MCA-Minimum Circuit Ampacity - 125 percent of the largest compressor RLA plus 100 percent of the second compressor RLA.
2. HACR type circuit breaker for CSA only. Fuse size (HACR breaker) 225 percent of the largest compressor RLA plus 100 percent
of the second compressor RLA.
3. Recommended Time Delay or Dual Element (RDE) Fuse Size - 150 percent of the largest compressor RLA plus 100 percent of
the second compressor RLA.
4. Local codes may take precedence.
5. Voltage Utilization range:
6. RLA-Rated Load Amps - Rated in accordance with UL Standard 1995.
7. LRA-Locked Rotor Amps - Based on full winding starts.
8. Data containing information on two circuits shown as follows: ckt 1/ckt 2.
