Trane R Series User Manual

RLC-SVX07A-EN 61
Installation - Electrical
Table 18 RTCA Electrical Data
Unit Wiring
Fan Motor Data Control KW
Unit Size
Rotated Voltage
(V/HZ/Phase) MCA (1)
Max. Fuse or
HACR (2)
Rec Time
Delay or
RDE (3)
Qty. KW FLA)
RTCA 70
200/60/3 39.6 40 40 8 1 4.8 0.75
230/60/3 39.6 40 40 8 1 4.8 0.75
460/6013 20.6 25 25 8 1 2.5 0.75
575/60/3 18.2 20 20 8 1 2.2 0.75
RTCA 80
200/60/3 39.6 40 40 8 1 4.8 0.75
230/60/3 39.6 40 40 8 1 4.8 0.75
460/60/3 20.6 25 25 8 1 2.5 0.75
575/60/3 18.2 20 20 8 1 2.2 0.75
RTCA 90
200/60/3 44.4 45 45 9 1 4.8 0.75
230/60/3 44.4 45 45 9 1 4.8 0.75
460/60/3 23.1 25 25 9 1 2.5 0.75
575/60/3 20.4 25 25 9 1 2.5 0.75
RTCA 100
200/60/3 49.2 50 50 10 1 4.8 0.75
230/60/3 49.2 50 50 10 1 4.8 0.75
460/60/3 25.6 30 30 10 1 2.5 0.75
575/60/3 22.6 25 25 10 1 2.2 0.75
RTCA 110
200/60/3 49.2 50 50 10 1 4.8 0.75
230/60/3 49.2 50 50 10 1 4.8 0.75
460/60/3 25.6 30 30 10 1 2.5 0.75
575/60/3 22.6 25 25 10 1 2.2 0.75
RTCA 125
200/60/3 49.2 50 50 10 1 4.8 0.75
230/60/3 49.2 50 50 10 1 4.8 0.75
460/60/3 25.6 30 30 10 1 2.5 0.75
575/60/3 22.6 25 25 10 1 2.2 0.75
(1) MCA - Minimum Circuit Am capacity - 125 percent of largest fan motor FLA plus 100 percent of the other fan motors FLAs.
(2) HACR type circuit breaker for CSA only. Fuse size (HACR breaker) 225 percent of the largest fan motor FLA plus 100 percent of
the other fan motor FLAs.
(3) RECOMMENDED TIME DELAY OR DUAL ELEMENT (RDE) FUSE SIZE: 150 percent of the largest fan motor FLA plus 100
percent of the other fan motor FLAs.
(4) RLA - Rated Load Amps - rated in accordance with UL Standard 1995.
(5) Local codes may take precedence.
(6) LRA - Locked Rotor Amps - based on full winding starts.
(7) VOLTAGE UTILIZATION RANGE:
(8) Data containing information on two circuits shown as follows: ckt 1/ckt 2
